- Page 1 Instruction Manual WOOD LATHE WL1220A IMPORTANT For your safety, read instructions carefully before assembling or using this product. Save this manual for Original Instruction future reference. V.2-201911...
- Page 2 INDEX GENERAL INFORMATION FOREWORD MACHINE IDENTIFICATION CUSTOMER SERVICE RECOMMENDATIONS SAFETY PRECAUTIONS SAFETY REGULATIONS RESIDUAL RISKS SAFETY AND INFORMATION SIGNALS SPECIFICATIONS MAIN COMPONENTS TECHNICAL SPECIFICATION ELECTRICAL CONNECTION NOISE LEVEL INSTALLATION INSTALL TOOL REST AND BASE ON LATHE BED SPINDLE LOCK ATTACHING SPUR CENTER ON THE HEADSTOCK KNOCKOUT BAR ATTACHING LIVE CENTER ON THE TAILSTOCK INSTALL THE FACEPLATE TO THE HEADSTOCK...
-
Page 3: General Information
1. GENERAL INFORMATION FOREWORD Some information and illustrations in this manual may difer from the machine in your possession, since all the configurations inherent in the machine complete with all the optionals are described and illustrated. Therefore, refer only to that information strictly connected with the machine configuration you have purchased. -
Page 4: Safety Precautions
2. SAFETY PRECAUTIONS SAFETY REGULATIONS Read carefully the operation and maintenance manual before starting, using, servicing and WARNING carrying out any other operation on the machine. The manufacturer disclaims all responsibilities for damages to persons or things, which might be caused by any failure to comply with the safety regulations. -
Page 5: Residual Risks
RESIDUAL RISKS Despite observance of all the safety regulations, and use according to the rules described in this manual, residual risks may still be present, among which the most recurring are: - contact with tool - contact with moving parts (belts, pulleys, etc..) - recoil of the piece or part of it - accidents due to wood splinters or fragments - tool insert ejection... -
Page 6: Main Components
3. SPECIFICATIONS MAIN COMPONENTS 10 11 12 1. Tailstock Locking Lever 8. Face Plate 2. Tailstock Hand Wheel 9. Spur Center 3. Tailstock Assembly 10. Tool Rest Base 4. Tailstock Locking Handle 11. Tool Rest 5. Live Center 12. Lathe Bed 6. -
Page 7: Noise Level
3.4 NOISE LEVEL No load Load Sound Pressure Level < 80dB(A) < 90dB(A) Sound Power Level < 90dB(A) < 100dB(A) The noise levels measured are emission levels and not necessarily the safe working level. Although there is a correlation between the emission levels and the exposure levels, this cannot be used reliably to determine whether or not further precautions are required. -
Page 8: Knockout Bar
4.3 ATTACHING SPUR CENTER ON THE Headstock Spindle Spur Center SPINDLE SPINDLE’S TOP HEADSTOCK - Insert spur center, with a No.2 Morse Taper shank, into the headstock spindle. Fig.4.3 4.4 KNOCKOUT BAR Knockout Bar TOP BAR - The knockout bar is used to remove the spur center from the headstock spindle. -
Page 9: Adjustments And Operations
4.7 INSTALL TOOL HOLDER ON THE LATHE - Located the tool holder from the carton, and install it onto the lathe bed with two pan head screws. Tool Holder TOOL HOLDER Pan Head Screw PAN HEAD SCREW Fig.4.7 4.8 SECURE LATHE TO A SOLID WORK SURFACE MOUNTING HOLES Mounting Holes... -
Page 10: Changing Spindle Speeds
5.3 CHANGING SPINDLE SPEEDS - The lathe features a three step motor and spindle pulleys to provide variable spindle speeds. Open access Belt Cover cover to change spindle speeds. 皮带护罩 - With access cover open, loosen locking handle. Raise Speed Control Dial 调速旋钮... - Page 11 -11-...
- Page 12 -12-...
