Digi Connectware AccelePort Xp 2p Installation Instructions

Pin Assignments
DB-25 and DB-9 Pin Assignments
Signal Description DB-25 Pin #
GND Chassis Ground Shell
TxD Transmitted Data
RxD Received Data
RTS Request To Send
CTS Clear To Send
DSR Data Set Ready
SG Signal Ground
DCD Data Carrier Detect
DTR Data Terminal Ready
RI Ring Indicator
RJ-45 Pin Assignments for 10-Pin and 8-Pin RJ-45 Connectors
Signal Description Pin # (of 10) Pin # (of 8)
RI Ring Indicator
DSR Data Set Ready
RTS Request To Send
GND Chassis Ground
TxD Transmitted Data
RxD Received Data
SG Signal Ground
CTS Clear To Send
DTR Data Terminal Ready
DCD Data Carrier Detect 10
† DSR (Pin 2 on a 10 pin connector, Pin 1 on an 8 pin
connector) can be swapped with DCD. This reverses the position
of these two signals in 10 pin or allows DCD to be used instead
of DSR on an 8 pin connector.
Consult the driver documentation for how to do this in your
specific operating system.
Refer to the CD-ROM for more detailed cabling information.
DB-9 Pin #
Shell
2 3
3 2
4 7
5 8
6 6
7 5
8 1
20 4
22 9
1 N/A
2† 1†
3 2
4 3
5 4
6 5
7 6
8 7
Digi, the Digi logo and AccelePort are trademarks or registered trademarks of Digi Interna-
tional in the United States and other countries. All other brand and product names are trade-
9 8
marks of their respective holders.
N/A
© Digi International Inc., 2002 All Rights Reserved; www.digi.com
Information in this document is subject to change without notice and does not represent a
commitment on the part of Digi International.
Digi provides this document "as is," without warranty of any kind, either expressed or
implied, including, but not limited to, the implied warranties of fitness or merchantability
for a particular purpose. Digi may make improvements and/or changes in this manual or in
the product(s) and/or the program(s) described in this manual at any time.
This product could include technical inaccuracies or typographical errors. Changes are peri-
odically made to the information herein; these changes may be incorporated in new editions
of the publication.
91001019_B
AccelePort Xp Family:
Adapter Installation
Introduction
® ™
An AccelePort Xp host adapter easily expands the number of
EIA-232 ports available on your computer, allowing you to cable
additional peripheral devices, such as modems, terminals or serial
printers, directly to your computer.
The 2p adapter has two male DB-9 connectors, each providing an
EIA-232 peripheral port connection.
The AccelePort 4p RJ45 adapter provides four RJ45 connectors for
multiple EIA-232 serial devices.
The 4p and 8p adapters have one HD-68 connector to which a special
Digi connector assembly is attached to provide the peripheral port
connections. There are five different connector assembly options
available from Digi to use with 4p and 8p adapters:
• RJ-45 Connector Box
• DB-25 Connector Box
• DB-9 Connector Box
• DB-25 Fan-out Cable
• DB-9 Fan-out Cable
The 16p adapter has two HD-68 connectors and accommodates two of
the above assemblies (in any combination), or a 16-port rack-mountable
connector box configurable with either DB-25 or RJ-45 connectors.
This installation guide describes how to plan your setup and install an
AccelePort Xp host adapter.
2p, 4p, 8p, 16p
PCI Host Adapters
EIA-232
Instructions
