At this point the hardware installation for your AccelePort Xr 920 host
adapter is complete. However, since the adapter must have software
downloaded to its RAM before it becomes functional, you must next
install the software drivers for your operating system.
Read the instruction booklet for the CD-ROM that came with your
adapter for instructions on installing software.
View the on-line documentation on the CD-ROM for more informa-
tion about AccelePort products.
The Digi logo and AccelePort are registered trademarks of Digi International. Xr 920,
4r 920, and 8r 920 are trademarks of Digi International.
All other brand and product names are trademarks of their respective holders.
© Digi International Inc., 1998
All Rights Reserved
http://www.dgii.com
Information in this document is subject to change without notice and does not represent a
commitment on the part of Digi International.
Digi provides this document "as is", without warranty of any kind, either expressed or
implied, including, but not limited to, the implied warranties of fitness or merchantability
for a particular purpose. Digi may make improvements and/or changes in this manual or in
the product(s) and/or the program(s) described in this manual at any time.
This product could include technical inaccuracies or typographical errors. Changes are peri-
odically made to the information herein; these changes may be incorporated in new editions
of the publication.
91000740 A
AccelePort
4r 920 and 8r 920
Installation Guide
Introduction
®
An AccelePort
Xr 920
host adapter easily expands the number of
EIA-232 ports available on your computer, allowing you to cable addi-
tional peripheral devices, such as modems, terminals or serial printers,
directly to your computer.
As shown in the figure below, an Xr 920 host adapter has one connector
to which a special Digi connector assembly is attached to provide the
peripheral port connections. There are three different connector assembly
options available from Digi to use with an Xr 920 host adapter: an RJ-45
Connector Box, a DB-25 Connector Box, or a DB-25 Cable Assembly.
Figure 1.
Example 4r 920 host adapter with connector assemblies
This installation guide describes how to plan your setup and install an
AccelePort Xr 920 host adapter.
Xr 920 Family:
PCI Host Adapters
EIA-232
Hardware
