Assembly Instructions
Turbocharger /
A100-M radial
Original assembly instructions – English
This document is valid for the
A100-M series:
A130-M, A135-M, A140-M, A145-M
Purpose
The assembly instructions explain how
the turbocharger is fitted to the engine
correctly and without any health and
safety risks.
Target group
The assembly instructions are intended
for engineers and mechanics responsi-
ble for fitting the turbocharger
on the engine.
Advertisement
Table of Contents
Related Manuals for Accelleron A130-M
Summary of Contents for Accelleron A130-M
- Page 1 Turbocharger / A100-M radial Original assembly instructions – English This document is valid for the A100-M series: A130-M, A135-M, A140-M, A145-M Purpose Target group The assembly instructions explain how The assembly instructions are intended the turbocharger is fitted to the engine...
-
Page 3: Table Of Contents
Fastening the turbocharger with a clamping nut ............ 14 Connecting the turbocharger................17 Attaching the support ..................17 Storage of new turbochargers and spare parts ....... 18 Further information ................ 21 © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C May 2022... -
Page 4: Introduction
Introduction Purpose of the assembly instructions The assembly instructions explain how the Accelleron turbocharger is fitted to the engine correctly and without any health and safety risks. This element of the documentation is supplied with the product, as is required for partly completed machinery in accordance with Machinery Directive 2006/42/EC. -
Page 5: Definition Of Warning, Caution, Note
Accelleron Industries Ltd is referred to in this document as Accelleron. Official Accelleron service stations Accelleron service stations are regularly audited and certified by Accelleron Industries Ltd (see "Con- tact Information" on the website www.accelleron-industries.com). Definition of warning, caution, note... -
Page 6: Definition Of Mandatory Signs
Dispose of in an environmentally with specifications compatible, professional way and in compliance with locally applic- Oil free, grease free and dry able regulations. Table 3: Definition of pictograms © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C May 2022... -
Page 7: Safety
Introduction State of the art Turbochargers manufactured by Accelleron are state of the art and comply with the respective health and safety standards in effect at the time the turbocharger was built. This ensures safe opera- tion of the turbocharger. -
Page 8: Lifting Of Loads
Use a suitable edge guard if there are sharp edges. The assembly devices must be completely screwed in and must not unscrew during use. Use assembly devices only for the described applications. © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C... -
Page 9: Occupational Safety
Keep flammable objects and substances out of the vicinity of flying sparks. Cover all connections on the turbocharger so that no foreign objects can enter the turbocharger. Wear personal protective equipment (PPE) for welding operations. © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C... - Page 10 Observe the information in the material safety data sheet for the operating ma- terials and supplies. Comply with local legislation. Wear safety goggles. Wear safety gloves to protect against mechanical hazards. Wear a respiratory mask to protect against gases. © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C May 2022...
-
Page 11: Weight And Transportation Of The Turbocharger
B Turbocharger with water-cooled bearing casing C Complete turbocharger unit with gas outlet casing Product Weight of complete turbocharger unit [kg] A130-M A135-M A140-M A145-M Table 4: Weight of complete turbocharger unit © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C May 2022... -
Page 12: Installing The Turbocharger
Always use new gaskets and insert them carefully into the slot. The oil is supplied (02) and drained (03) through the bracket (01). The necessary sealing is provided by O-rings. The O-rings are not included in the Accelleron scope of delivery. Bracket... -
Page 13: Fitting Threaded Rods
The threaded rods and nuts for fastening the turbocharger on the bracket are not included in the Ac- celleron scope of delivery. The clamping nuts are included in the Accelleron scope of delivery. © Copyright 2022 Accelleron Industries. All rights reserved. -
Page 14: Placing The Turbocharger On The Bracket
Fastening the turbocharger with a clamping nut →14 The gas outlet casing (61001) may still be fitted in the exhaust gas pipe if the locking nuts remain ac- cessible for removing the turbocharger. © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C... -
Page 15: Fastening The Turbocharger With A Standard Nut
**) When the turbocharger is mounted on the engine support, the bolt threads and screw heads must be lightly oiled (assumed friction coefficient µ = 0.12 for tightening torque) Remove the lifting gear. © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C... -
Page 16: Fastening The Turbocharger With A Clamping Nut
4. Tighten clamping nut (03) by hand. 5. Unscrew clamping nut (03) by ¼ of a turn (90°). The distance between the thrust washer and the clamping nut is now about 1 mm. © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C... - Page 17 5. Tighten clamping nut (03) by hand. 6. Unscrew clamping nut (03) by ¼ of a turn (90°). The distance between the thrust washer and the clamping nut is now about 1 mm. © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C...
- Page 18 4. Work in a circle to tighten all pressure screws to 100 % of the tightening torque specified in the table. 5. Tighten pressure screws to 100 % in 5 … 7 rounds until the required residual tightening angle of < 20° is achieved. © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C May 2022...
-
Page 19: Connecting The Turbocharger
Remove the screw plug on the connection for the compressor wheel cooling (06) and fit the cool- ing air line. Attaching the support Fig. 11: Attaching the support If present: Attach support (61301) to engine support or to a connecting piece. © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C May 2022... -
Page 20: Storage Of New Turbochargers And Spare Parts
Long-term storage of turbochargers The turbochargers will be prepared for long-term storage if requested in the purchase order. The package is equipped with a hygrometer (see illustration). © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C May 2022... - Page 21 Inspect the package for damage. If the package is damaged, the turbocharger must be inspected by a Accelleron service station and repacked. After every 3 years the following work steps must be performed by a Accelleron service station: ¡ Inspect the component ¡...
- Page 22 Assembly Instructions / A130-M.. - A145-M.. 5 Storage of new turbochargers and spare parts / © Copyright 2022 Accelleron Industries. All rights reserved. HZTL455311P0005_EN Rev. C May 2022...
-
Page 23: Further Information
