mxr Third Man Hardware Double Down Quick Start Manual

MXR x Third Man Hardware

Double Down Pedal

MXR and Third Man Hardware have teamed up to

create the perfect booster for gigging guitar players.

The Double Down Pedal combines two separate MXR

Micro Amp circuits into a single box so that you can

dial in just the right amount of classic Micro Amp

bump for both of your signal chains.

jimdunlop.com

™

CSP042

Table of Contents

Need help?

Do you have a question about the Third Man Hardware Double Down and is the answer not in the manual?

Page 1 ® Double Down Pedal ™ MXR and Third Man Hardware have teamed up to create the perfect booster for gigging guitar players. The Double Down Pedal combines two separate MXR Micro Amp circuits into a single box so that you can dial in just the right amount of classic Micro Amp bump for both of your signal chains.
Page 2 GAIN 2 knob sets output level of OUT 2 signal PHASE switch selects stereophonic effect (yellow LED indicates on) BUFFER switch selects true/buffered bypass (yellow-orange LED indicates buffered bypass) CSP042 | MXR x Third Man Hardware Double Down Pedal 2 ® ™...
Page 3 Basic Operation Power Directions The MXR x Third Man Hardware Double Down Pedal 1. Run an instrument cable from your instrument to the ® ™ is powered by one 9-volt battery (remove bottom plate to CSP042’s INPUT jack. Run two more instrument cables install), a 9-volt AC adapter such as the Dunlop ECB003/ from the CSP042’s OUT 1 and OUT 2 jacks to two...
Page 4 > 450 k Ω Buffer ON > 700 k Ω Output Impedance < 1 k Ω Bypass Buffered/True Bypass Current Draw 11 mA Power Supply 9 volts DC CSP042 | MXR x Third Man Hardware Double Down Pedal 4 ® ™...
