Installation Guide GSF3 & GSF6 Landscape Speakers CAUTION: Installation must be done by qualified persons using safe installation standards. The installer is responsible for proper selection and use of mounting hardware and processes to install the speakers in a safe manner. Wire Connection •...
Page 2
Setting TAP SELECTOR SWITCH ROTARY TAP SELECTOR SWITCH (TAP SELECTOR SWITCH is located on the bottom of the speaker enclosure) • Rotate bottom-panel TAP SELECTOR SWITCH to select between: GSF3: 8Ω (ie, low-impedance / direct) 15W or 7.5W for either 70V or 100V distributed speaker system 3.75W for 70V distributed speaker system only GSF6: 8Ω...
Page 3
• Use the included 3 mm hex wrench to tighten the 3 set screws to hold the chosen base securely. • For GROUND-STAKE BASE, press base into the ground. CAUTION WHEN RE-AIMING SPEAKER: When ground-stake is utilized, re-aiming speaker horizontally requires either: a) completely pulling stake from ground and re-pressing back into ground at new aiming angle, or b) loosening 3 set screws, re-aiming speaker, and re-tightening set...
Page 4
