IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0333 777 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to
be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of two persons is required to assemble this product.
PRODUCT INFORMATION
• Made from honeycomb board,particle board & MDF with a wood effect finish.
• Made in China.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not use furniture polish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching
or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
STANTON CORNER DESK AND SHELF
STANTON CORNER DESK AND SHELF
STANTON CORNER DESK AND SHELF
STANTON CORNER DESK AND SHELF
ASSEMBLY INSTRUCTIONS.
Page 1 of 6
Advertisement
Table of Contents
Related Manuals for Next STANTON 133228
Summary of Contents for Next STANTON 133228
- Page 1 STANTON CORNER DESK AND SHELF STANTON CORNER DESK AND SHELF STANTON CORNER DESK AND SHELF STANTON CORNER DESK AND SHELF ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0333 777 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to...
- Page 2 FITTINGS PARTS STEP ONE 1.Insert 10x cambolts (D) into panels 2, 3 & 5 and tighten with a screwdriver. STEP TWO 1.Glue (B) and insert 2 x wooden dowels (A) into panel 2. 2.Attach panel 4 to panel 2 3.Insert 2x camlocks (C ) into panels 4 and tighten with a screwdriver.
- Page 3 STEP THREE 1.Insert 5x cambolts (D) into panel 1 and tighten with a screwdriver. 2. Attach metal plate (G) to leg 13 with 1x bolts (E) using an Allen key (F) to tighten. 3.Insert 2 x bolts (K) into nuts fixed on panel 1 and turn bolts (K) clockwise until tight by hands.
- Page 4 STEP SIX 1.Insert 8x cambolts (D) into panels 7 & 8 and tighten with a screwdriver. STEP SEVEN 1.Glue (B) and insert 8 x wooden dowels (A) into panel 7. 2. Attach panels 10,12 & 11(x2) to panel 7 3. Insert 4 x camlocks (C) into panels 10,12 & 11(x2) tighten with a screwdriver.
- Page 5 STEP NINE 1.Glue (B) and insert 8 x wooden dowels (A) into panel 10,12 & 11(x2) 2. Attach panel 8 to panels 10,12 & 11(x2) 3. Insert 4 x camlocks (C) into panels 10,12 & 11(x2) tighten with a screwdriver. Ensuring the arrow indicator is pointing toward the panel edge before tightening with a screwdriver...
- Page 6 3.Check shelves periodically to see that no fittings as loosened and needs attention. STEP FOURTEEN 1.The diagram for your reference . Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 6 of 6...
