- Page 2 HOTEL HEADBOARD 130430 / 123511 / 145133 Assembly Instructions Actual product size H60 x W120 x D8 CM Produced in the UK for Next Retail Ltd. 130430 / 123511 / 145133 - 2016 V2...
- Page 3 Unwrap all packaging materials and place the components on a clean surface to protect it from damage, To clean your item, please use a vacuum or lightly brush clean Produced in the UK for Next Retail Ltd. 130430 / 123511 / 145133 - 2016 V2...
- Page 4 Use a spirit level to ensure they are straight. SUPERKING KING Cut away a small patch to reveal the hanging holes on the back of the headboard. Produced in the UK for Next Retail Ltd. 130430 / 123511 / 145133 - 2016 V2...
- Page 5 From your markings on the wall; Measure out the locations for the fixing holes as per the be- low diagram and mark these points on the wall with a pencil. 685mm 255mm 105mm 385mm Produced in the UK for Next Retail Ltd. 130430 / 123511 / 145133 - 2016 V2...
- Page 6 X4 PER HEADBOARD 20mm Leave 20mm of the screw from the wall to allow the fitting of the headboards. Produced in the UK for Next Retail Ltd. 130430 / 123511 / 145133 - 2016 V2...
- Page 7 HB down about 15mm. Make sure the HB is secure before use TIP: If you’re fitting more than one HB start with the lower one first 15mm Produced in the UK for Next Retail Ltd. 130430 / 123511 / 145133 - 2016 V2...
