- Page 1 OPERATOR’S MANUAL 2646E-OR 3346E-OR 4046E-OR 4646E-OR 2646E-OR serial # 2264601000 - Current 3346E-OR serial # 2334601000 - Current 4046E-OR serial # 2404601000 - Current 4646E-OR serial # 2464601000 - Current November 2020 81251...
- Page 2 GMG 2646E-OR --- 4646E-OR Operator’s manual Specifications MODELS 2646E-OR 3346E-OR 4046E-OR 4646E-OR Measurements Working height maximum 32’ (10 m) 39’ (12 m) 46’ (14.04 m) 51’ 6” (15.9 m) Platform height maximum 26’ (8 m) 32’ 8” (10 m) 39’ 6” (12.04 m) 45’...
-
Page 3: Table Of Contents
Table of Contents Introduction Introduction .......................1 Safety Safety ........................2 Safety Alert Symbols ..................2 Fall Protection ....................3 Hazards Electrocution Hazard ..................4 Tip-over Hazards ....................5 Fall Hazards .......................6 Collision Hazards ....................6 Additional Safety Hazards .................7 Component Locations Component Locations ..................8 Platform Controls ....................9 Lower Controls .................... - Page 4 This Operator’s Manual has been designed to provide you, the owner, user or operator, with the instructions and operating procedures essential to properly and safely operate your GMG Aerial Work Platform for positioning personnel, along with their necessary tools and materials, to overhead work locations.
-
Page 5: Safety Safety
For your safety and the safety of those around you, you must operate your machine as in- structed in this manual. GMG designs aerial work platforms to safely and reliably position personnel, along with their necessary tools and materials, at overhead work locations. The owner/user/operator of the machine should not accept responsibility for the operation of the machine unless properly trained. - Page 6 GMG 2646E-OR --- 4646E-OR Operator’s manual Operators must comply with employer, job site and governmental rules regarding the use of personal protective equipment. If required by your employer or job site, use personal fall protection equipment (PFPE) when operating this machine.
- Page 7 ELECTROCUTION HAZARD! THIS MACHINE IS NOT INSULATED! DEATH OR SERIOUS INJURY will result from contact with or inadequate clearance from any electrically charged conductor. You must maintain a CLEARANCE OF AT LEAST 3.05 m between any part of the machine, or its load, and any electrical line or apparatus carrying over 300 Volts up to 50,000 Volts.
- Page 8 NEVER replace any part of the machine with items of different weight or 13307 specification. DO NOT ELEVATE IN NEVER modify or alter the work platform without written permission from GMG. WINDY CONDITIONS NEVER place ladders or scaffolds in the platform or against any part of the machine.
- Page 9 DO NOT sit, stand or climb on the platform guard rails. Maintain a firm footing on the platform floor at all times. DO NOT exit the platform when elevated Keep the platform floor clear of debris. DO NOT fasten a fall restraint lanyard to an adjacent structure. Ensure that all gates are properly closed and secured before operating the machine.
-
Page 10: Hazards
GMG 2646E-OR --- 4646E-OR Operator’s manual DDITIONAL AFETY AZARDS Explosion and Fire Hazards • DO NOT operate the machine in hazardous locations or locations where potentially flammable or explosive gases or particles may be present. Damaged Machine Hazards • Conduct a thorough prestart inspection of the machine and test all functions before each work shift to check for damage, malfunction and unauthorized modification. -
Page 11: Platform Controls
General Locations Guardrails Platform Extension Deck Release Extension Deck Maintenance Lock Lift Cylinder Entry Ladder Manuals Platform Case Controls Chassis Battery Disconnect Tie-Down/ Lift Points Lower Controls Station Leveling Lower Emergency Outriggers Stop Switch Entry Gate Emergency Lowering Knob Forklift Pockets Charging Location www.GoGMG.com Page 8... - Page 12 GMG 2646E-OR --- 4646E-OR Operator’s manual Series: 2646 --- 4646 E-OR E-OR Page 9 November 2020 #81250.1...
- Page 13 Control Description Push LEFT side of switch to steer LEFT Steer Switch Push RIGHT side of switch to steer RIGHT Drive Controls Forward and Reverse travel Move toward operator to ELEVATE platform. Lift speed Joystick Lift increases proportional to the Joystick movement. Move away from operator to LOWER platform.
- Page 14 GMG 2646E-OR --- 4646E-OR Operator’s manual HOURS Be aware of the machine’s position and of your surroundings before activating any control function. Control Description Emergency Stop Push IN to stop all functions Pull OUT to reset Platform Lift/Lower Switch With the Key Switch in the LOWER position, move this switch up to lift the...
-
Page 15: Workplace Inspection
DO NOT operate this machine until you have read and understood this manual, have performed the Workplace Inspection, Pre-Start Inspection and Routine Maintenance, and have completed all the test operations detailed in the Operating Instructions section. Inspect the workplace and determine whether the workplace is suitable for safe machine operation. Do this before moving the machine to the workplace. -
Page 16: Operating Instructions
GMG 2646E-OR --- 4646E-OR Operator’s manual DO NOT operate this machine until you have read and understood this manual, have performed the Workplace Inspection, Prestart Inspection and Routine Maintenance, and Functions Test, have inspected the jobsite for hazards, and have learned the operating procedures for this machine. - Page 17 • Perform Prestart Inspection. • Check platform control Emergency Stop Switch - pull OUT to reset. 1. Select a test area that is firm, level, and free of obstruction. 2. Be sure the battery pack is connected by checking that the RED disconnect switch is pulled out. 3.
- Page 18 GMG 2646E-OR --- 4646E-OR Operator’s manual 14. Activate the UP function and raise the platform approximately 60 cm. 15. Pull the red EMERGENCY LOWERING knob, found at the back of the machine above the step. Result: The platform should lower. The descent alarm will not sound.
- Page 19 25. Activate the Drive functions by pressing the DRIVE-FUNCTION BUTTON. Once pressed - the LED light in this button will illuminate. 26. Press and hold the FUNCTION ENABLE SWITCH on the control handle. 27. Depress the THUMB ROCKER SWITCH on top of the control handle in the direction identified by the blue left arrow on the control panel.
- Page 20 GMG 2646E-OR --- 4646E-OR Operator’s manual Check the area above and around the machine for obstructions and electrical power lines before operating the machine. 1. Turn the KEY SWITCH to LOWER CONTROLS. 2. Pull the EMERGENCY STOP to the ON position at both the lower and platform controls.
- Page 21 1. Activate the Drive-functions by pressing the DRIVE-FUNCTION BUTTON. 2. Press and hold the FUNCTION ENABLE SWITCH on the CONTROL HANDLE. • Increase speed: Slowly move the CONTROL HANDLE off center. • Push the CONTROL HANDLE forward to move forward. Pull the CONTROL HANDLE reverse to move reverse.
- Page 22 GMG 2646E-OR --- 4646E-OR Operator’s manual DO NOT drive the machine on a slope with the platform elevated. The platform must be in the fully stowed position before driving on a slope. Determine the slope and side slope ratings for the machine and determine the slope grade.
- Page 23 1. Press the Platform Lock Pin Foot Pedal on the extension deck. 2. Push the platform extension guardrail to extend the platform to the desired position. Do not stand on the platform extension while extending or retracting it. Platform Lock Pin Foot Pedal IF THE ROLL-OUT DECK IS EXTENDED CHECK FOR CLEARANCE UNDER DECK AREA BEFORE LOWERING PLATFORM.
- Page 24 Charge the battery in a well-ventilated area. Use proper AC input voltage for charging as indicated on the machine. Use only GMG authorized batteries and chargers. IMPORTANT — Be sure to disconnect the charger from the outlet before attempting to operate the unit.
- Page 25 DO NOT operate this machine until you have read and understood the Safety section of this manual, have performed the Jobsite Inspection, Pre-Start Inspection and Routine Maintenance, and have completed all the test operations detailed in the Operating Instructions section. The operator must conduct a thorough Pre-Start Inspection of the machine and test all functions before each work shift to check for damage, malfunction and unauthorized modification.
- Page 26 GMG 2646E-OR --- 4646E-OR Operator’s manual The operator conduct a Pre-Start Inspection of the machine before each work shift. DO NOT use a damaged or malfunctioning machine. Initial Description Be sure that the operator’s manual is complete, legible and in the storage container located in the platform.
- Page 27 This checklist must be used at 3-month intervals or every 150 hours of machine use, whichever occurs first. Failure to do so could result in death or serious injury. Scheduled Maintenance Inspections should be conducted by qualified service technicians only. Photocopy this page for reuse.
- Page 28 GMG 2646E-OR --- 4646E-OR Operator’s manual This checklist must be used at quarterly intervals or every 300 hours of machine use, whichever occurs first. Failure to do so could result in death or serious injury. Scheduled Maintenance Inspections should be conducted by qualified service technicians only. Photocopy this page for reuse.
-
Page 29: Annual Inspection Report
Annual Inspection Report Date Serial Number Model Number Global Machinery Group, Inc. Date Of Last Inspection 3428 Bullock Lane, San Luis Obispo, CA 93401 USA Date Placed In Service 800-301-0499 • 805-303-2066 • Fax: 805-293-6211 Customer Dealer Street Street City/State/Zip City/State/Zip Phone Number Phone Number... - Page 30 GMG 2646E-OR --- 4646E-OR Operator’s manual DO NOT operate this machine until you have read and understood the Safety section of this manual, have per- formed the Jobsite Inspection, Pre-Start Inspection and Routine Maintenance, and have completed all the test operations detailed in the Operating Instructions section.
-
Page 31: Maintenance
Important - The operator may perform routine maintenance only. Scheduled maintenance must be performed by qualified service technicians. Pre-Start Inspection • Perform routine maintenance as identified in the Pre-Start Inspection Checklist. Scheduled Maintenance Maintenance performed monthly, quarterly, annually and bi-annually must be performed by a qualified service technicians trained and authorized to perform maintenance on this machine, and must be done in accordance with the procedures outlined in the service manual. -
Page 32: Routine Maintenance
GMG 2646E-OR --- 4646E-OR Operator’s manual Operator may perform routine maintenance only. Lubrication listed as Scheduled Maintenance must be performed by a qualified service technician. FULL 13327 ITEM SPECIFICATION FREQUENCY HYDRAULIC Mobile Fluid DTE 10, DTE 13M or AW32. Routine Maintenance... - Page 33 The serial plate is attached to the machine at the time of manufacture. Important information about the machine is recorded on the serial plate. G G M M G G MODEL NUMBER SERIAL NUMBER (GLOBAL MACHINERY GROUP, INC) Serial Plate 3346E-OR xxxxxxxxxxx Corporate office...
- Page 34 Obvious fluid leak or damaged component? • Wires disconnected, broken, or loose? • Motor control processor Diagnostic LED OFF? LED should be ON. If not N or FLASHING, refer to Service Manual or contact GMG Technical Support. Series: 2646 --- 4646 E-OR E-OR Page 31 November 2020 #81250.1...
- Page 35 GMG machinery. Drivers are responsible for loading and securing machines, and should be properly trained and authorized to operate GMG machinery. Drivers are also responsible for selecting the correct and appropriate trailer according to government regulations and company policy.
- Page 36 GMG 2646E-OR --- 4646E-OR Operator’s manual GMG does not recommend unassisted loading or unloading. Always attach the machine to a winch when loading or unloading from a truck or trailer by driving. Read and understand all safety, control, and operating information found on the ma- chine and in this manual before operating the machine.
- Page 37 Only qualified riggers should rig and lift the machine. Ensure that the crane capacity, loading surfaces and straps are sufficient to withstand the machine weight. See the serial plate for the machine weight. Process • Fully lower the platform. Be sure the deck extension is retracted and the compartment doors are closed and secure.
- Page 38 GMG 2646E-OR --- 4646E-OR Operator’s manual Series: 2646 --- 4646 E-OR E-OR Page 35 November 2020 #81250.1...
- Page 39 www.GoGMG.com Page 36...
- Page 40 GLOBAL MACHINERY GROUP, INC. 3428 Bullock Lane San Luis Obispo, CA 93401 USA Tel USA: +1.805.303.2066 Toll Free (USA/Canada): 800.303.0499 www.goGMG.com...
