Summary of Contents for MaxVac DV15 HYDRO

  • Page 1 DV15 HYDRO INSTRUCTION INSTRUCTION MANUAL MANUAL...
  • Page 3: Table Of Contents

    ENGLISH INSTRUCTION MANUAL WARNINGS TECHNICAL SPECIFICATION USING THE APPLIANCE MAINTENANCE ACCESSORIES TROUBLESHOOTING EU DECLARATION OF CONFORMITY DV15 Hydro MAX-VAC.COM...
  • Page 4: Warnings

    Do not pull the power cord around sharp edges and avoid pinching or crushing it. • Never leave the appliance running unattended. • Never leave the appliance where it could be damaged by the weather (rain, cold, sun, etc.). DV15 Hydro MAX-VAC.COM...
  • Page 5 Use only water to clean the appliance. Do not use trichloroethylene, solvents, or abrasive detergents. The manufacturer will accept no responsibility for damage that may occur due to improper use, failure to follow the instructions in this manual, modifications, or poor maintenance. 230V~ 50/60Hz DV15 Hydro MAX-VAC.COM...
  • Page 6: Technical Specification

    TECHNICAL SPECIFICATION DV15 HYDRO 230 V~ Power supply voltage 50/60 Hz Frequency 230V = 1100 W Power Rating 165 m3/h Maximum airflow approx Drum made of 15 Liters Rated drum capacity 19 KPa (approx) MAX suction approx Motor insulation class...
  • Page 7: Using The Appliance

    ALWAYS use the foam filter in the dry and liquid vacuuming function • (MV-DV-ACC-106). • Place the foam filter on the motor housing (c). • Refit the motor unit to the drum. “c” CAUTION WATER LEVEL The “particle separator” must be removed when vacuuming liquids DV15 Hydro MAX-VAC.COM...
  • Page 8 Switch off the appliance immediately, release the motor unit and empty the drum. 3. TO VACUUM LARGE QUANTITIES OF LIQUID • When vacuuming liquids from containers, make sure the crevice tool is never fully submerged to ensure partial air flow. DV15 Hydro MAX-VAC.COM...
  • Page 9: Maintenance

    3 - REPLACING THE POWER CORD • Contact an authorised service centre (see list attached) if the power cord has been damaged, since special tools are needed to replace it. DV15 Hydro MAX-VAC.COM...
  • Page 10: Accessories

    flexible hose for grip and pneumatic tool downflow device with universal adapter DV-ACC-114 DV-ACC-102 DV-ACC-101 DV-ACC-100 Floor bar Floor bar insert Floor bar insert Floor bar insert housing for for liquids for hard floors for carpets combined brush DV15 Hydro MAX-VAC.COM...
  • Page 11 ACCESSORIES DV-ACC-104 DV-ACC-124 DV-ACC-110 DV-ACC-105 Crevice tool Multi-diameter Round brush Triangular adapter accessory DV-ACC-106 DV-ACC-108 DV-ACC-111 MV-ACC-302 Foam filter for M-Class Pre-filter "IFA" double- vacuuming liquids Cartridge Filter layer fleece filter with Adapter bags Disk DV15 Hydro MAX-VAC.COM...
  • Page 12: Troubleshooting

    If it is blocked, clean the seating it slides along and that is an integral part of the housing. DV15 Hydro MAX-VAC.COM...
  • Page 13: Eu Declaration Of Conformity

    EN61000-3-3:1995 + A1:2001 + A2:2005 EN61000-4-2:1995 + A1:1998 + A2:2001 EN61000-4-3:1996 + A1:1998 + A2:2001 EN61000-4-4:1995 + A1:2001 + A2:2001 EN61000-4-5:1995 + A1:2001 EN61000-4-6:1996 + A1:2001 EN61000-4-11:1994 + A1:2001 This declaration was written up in November 2010. DV15 Hydro MAX-VAC.COM...
  • Page 14 DV15 Hydro MAX-VAC.COM...
  • Page 15 DV15 Hydro MAX-VAC.COM...
  • Page 16 Mülibodenstrasse 3 CH-8172 Niederglat Zürich, Schweiz +41(0) 43 411 4195 max-vac.com...
