MobiBlu DAH-900 User Manual

MobiBlu DAH-900 User Manual

Multi format digital audio player

Advertisement

Quick Links

Safety Warnings and Cautions
Please be aware of these safety instructions and use the product
properly in order to prevent risks of injury or damages to the property.
warning
subject to cause death or severe injury
subject to cause minor injury or damages to
Cautions
the property
indicates prohibitions to
Indicates prohibitions
be disassemble
Indicates prohibitions
indicates strict obligations
to touch
Warnings
Avoid places with high moisture or dust
Never disassemble, repair nor rebuild
level (It can cause damage to the
(It becomes cause for troubles.)
product.)
Avoid exposure to direct sunlight (High
Don t connect the product to the power
nor touch the product with wet hands
heat applied to the product can
(There is a risk of an electric shock.)
damage it.)
Cautions
Warning
To reduce the risk of fire or electric shocks, do not expose the product to rain or
other moist environment.
It is an illegal act to distribute any music file, of WMA or MP3 format, to others
without permission, violating copyright laws. The use of software in the CD-ROM
provided is limited to personal purpose only.
In order to maintain optimal performance
Do not use this product under extremely hot or cold, or excessively dusty or moist
environment.
Do not place the product in the following places: in a bathroom, near heater or on
a dashboard of a car where it is exposed to direct sunlight.
When carrying the product in a pocket with batteries in place, do not keep together
metal items such as coins or keys. Contact or friction between metals and the
battery may cause fire.
We are not responsible for the loss of data stored on the product due to user
carelessness (please backup important data)
Avoid impact on the product
Do not drop the product or do avoid any act of giving great impact on the product.
It may cause serious damage to the product.
caution when using headphones
To listen to music at high volume for a long time using headphones may cause
hearing problems.
Do not use headphones when driving a car, or riding a bicycle or motorcycle.
Pay extra caution or stop using headphones under potentially dangerous
situations, as when walking or jogging.
The earbud-type headphones must be attached to a long string, and when
using such headphones, the string must be let behind your neck.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAH-900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MobiBlu DAH-900

  • Page 1 Safety Warnings and Cautions Please be aware of these safety instructions and use the product properly in order to prevent risks of injury or damages to the property. warning subject to cause death or severe injury subject to cause minor injury or damages to Cautions the property indicates prohibitions to...
  • Page 2: Table Of Contents

    Welcome to the World of Player Thank you for purchasing the DHA-900, a portable digital audio player. Player is an MP3 player that is simple and thin in design with built-in FM Radio. Player is equipped with internal memories, 64/96/128/256/512MB. It supports the latest music file formats and is designed to conform to intellectual properties issues.
  • Page 3: What Is A Digital Audio Player

    1. Accessories and option products may change depending on the product characteristics. 2. For the latest accessories and software for Player, please refer to http://www.mobiBLU.com 3. For WMA file type, only 32Kbps or higher bit rates are supported. The Product Specifications Category Item FM Frequency Range 87.5MHz ~ 108.0MHz...
  • Page 4: Pc System Requirements And Accessories

    PC System Requirements and Accessories PC system requirements for Player are as follows: Microsoft OS (Windows 98, ME, 2000, XP) CD_ROM Drive Pentium 200MHz or higher CPU 32MB (64MB for Windows ME or 2000) or higher RAM Available hard disk space of more than 128 MB (additional hard disk space is need for storing music files) may use USB port Player Items in the Package...
  • Page 5: About Power Supply

    About Power Supply Using cylindrical AAA type batteries Open the battery cover on the back by pushing it in the direction of arrow. Insert AAA batteries with correct polarity positions as shown in the picture. Inserting batteries in wrong polarity positions may cause damage to the product One or two 1.5V AAA-type batteries are needed After fitting the cover to the groove, push it...
  • Page 6: Software Installation

    Software Installation 1. When you insert the installation CD in the CD-ROM drive, the following screen appears. [Click] Click! Click! 2. When the following screen appears, select the folder you wish the program to be installed in and click [next] button. Click! Click! Software Installation...
  • Page 7: Connecting The Player To A Pc Using A Usb Cable

    Connecting the Player to a PC using a USB Cable Note Tthe digital audio turns on when connect USB USB port. 1. Connect one end of a USB cable to one of the USB ports on the back of the PC, and connect the other end to the player. note: The LCD displays Player...
  • Page 8: File Download/Upload

    File Download/Upload 1. Connect Player to the PC. 2. Execute Windows Explorer. 3. Select the file you wish to download/upload, then store the file in the folder selected using “Copy -> Paste” or Drag & Drop. Note LCD display shows “ RITING” during file downloading. Unplugging the cable while still downloading/uploading may cause malfunction of the product.
  • Page 9: Formatting

    Formatting 1. To format using Player program: After connecting the player to the PC using a USB cable, select and exeute “Hyunwon inc DAH900 Mp3 Player -> DAH900 Format” from “Start -> Programs”. Push the Start button to proceed. Be cautious as all files will be deleted and cannot be restored after the formatting.
  • Page 10: Lcd Display Illustration

    OS Update 3. Execute “HyunWon Inc DAH-900 Mp3 Player -> DAH-900 Update” from “Start -> Programs”. When the following message appears after 10 seconds, select [OK]. Click! Click! 4. Execute once again “HyunWonInc., DAH-900 Mp3 Player -> DAH-900 Update” from “Start -> Programs”.
  • Page 11: Power On/Play

    Power On / Play 1. Power ON( ): When you push the PLAY button on the product, its power turns on and it goes to the stop mode, after displaying the product logo. 2. Play: Music/Voice begins to play when you push the PLAY button( ) from the stop mode.
  • Page 12: Setting Volume/Lock Functions

    Setting Volume/Lock Functions 1. Volume Control You can control the volume level by using VOL + / VOL - button on the product while playing music. Volume level can be set within the range from MIN (00) to MAX (30). You can adjust the volume level step by step by pushing shortly, or adjust successively by pushing long.
  • Page 13: Voice Recording

    Voice Recoding 1. Voice recording starts when the REC/A-B button is pushed long enough. 2. When you push the STOP button( ), the recording process stops and a new voice file is created. The file is recorded in the order of V001, V002, … , in ADP file format. Voice recording stops automatically at the Memory Full ( Searching a Music/Voice File 1.
  • Page 14: Fm Mode

    FM Mode Choose FM mode using the MODE button. 1. Searching a frequency manually You can manually search for a desired frequency by pushing the FF/REW buttons shortly. 2. Store/Release of a frequency manually The frequency searched manually can be stored by pushing the MENU/HOLD button shortly.
  • Page 15: Fm Recording

    FM Recoding 1. Push and hold the REC button while listening to FM. It will start recording the FM broadcasting being received currently in an ADP file format. 2. Push the STOP button The recording will stop and the recorded file will be created in the voice folder.
  • Page 16: Selecting Menu

    Selecting MENU Pushing the MENU button shortly in music/voice mode changes it to MENU mode. Button specifications in MENU mode MENU mode status Duration Button Next status Current status Short No changes Menu Mode PLAY Long Short MENU mode released STOP Menu Mode Long...
  • Page 17: Display (Screen Setting)

    Setting 3. Search Speed Search speed controls the speed of Fast Search and it may be selected to one 16 / 4. Intro Play Time When you want to listen to the beginning parts of all the stored tracks, you can select one of 2”/4”/6”/8”/10”. 5.
  • Page 18: Timer

    Timer Auto Power Off (automatic power saving mode): At “MENU button -> Timer Select -> Auto Power Off”, push the MENU button to select the auto power save time. (Disable/1min/2min/5min/10min) Sleep Mode: At “MENU button -> Timer Select -> Sleep Mode”, push the MENU button to select the auto power save OFF time.
  • Page 19: Setting User Eq

    Setting USER EQ Setting USER EQ Player supports two USER EQs (USER EQ_1 USER EQ_2) 1) Select USER EQ on MENU 2) Setting User equalizer for User_EQ1, User_EQ2 3) Select User EQ from User_EQ1 and User_EQ2 4) You can control when the display shows 5 BARs (supports 5 Bands) 5) You can select Band using the FF/REW buttons.
  • Page 20: Deleting Files

    Deleting Files 1. When you push the MENU button in PLAY/STOP mode, the Setting Mode is displayed. Select “ERASE” using the FF/REW buttons. 2. When you push the MENU button shortly, a warning message “Are you sure you want to delete this file?” shows on the LCD screen. Choose “Yes” or “NO” using the FF/REW buttons.
  • Page 21: Menu Catalog

    MENU Catalog Remote Control Instructions Earphone Jack VOL+/ VOL- PLAY/PAUSE STOP HOLD EQ / MODE 1. The remote control is consisted of 7 buttons and a HOLD button (PLAY/STOP/VOL+/VOL-/FF/REW/EQ/HOLD) 2. All buttons except the EQ/MODE button have the same functions as in the player.
  • Page 22 Remote Control Instructions Mode switch function (Music Mode <-> FM Mode) When you push and hold the EQ/HOLD button long enough in music stop mode, it switches to FM mode. Play Mode switch function Pushing the EQ/MODE button shortly in stop mode changes the ‘Normal- Intro-….’...
  • Page 23: Warranty Services

    Hyunwon service center. 7. Natural disasters (fire, disaster from see wind, gas exposure, earthquake, storm and flood, etc.) For more detailed information, please visit the homepage of Hyunwon. Service Center TEL: 82-1588-3949 FAX: 82-54-337-2075 E-mail: many@hyunwoninc.com Homepage: www.mobiBLU.com Warranty Services...
  • Page 24: Warranty Policy

    Warranty Policy Warranty Detail Damage Type Within Warranty Period Replacement of product Major repair request within 10 or full refund of purchase days of purchase price Functional Repair request on main Replacement of components within 1 month of product performance purchase troubles Major repair request on a replaced...
  • Page 25 MEMO MEMO SRS is a registered trademark of SRS Labs. WOW Technology is an intellectual property of SRSLabs. B-grade Instruments (Information and Telecommunications Device for Home Usage) This device is registered to comply with the electro-magnetic wave regulations as a home device, and can be used in the home or other areas.
  • Page 26 A/S Inquiries: 82-1588-3949 www.mobiBLU.com Reception Desk in Seoul and Kyung-Ki Areas Tel: 82-2-2016-7899 Address: 25 Fl., Dosim Airport Tower, Samsung-dong, Kangnam-gu, Seoul Seoul Branch, Hyunwon Inc. User s Manual SRS WOW FM Radio Voice Recorder Multi Format Digital Audio Player DAH-900...
