Audio Technica 60th ANNIVERSARY AT-LP2022 Quick Start Manual

Quick Start Guide
AT-LP2022
Contents
Turntable body
Dust cover
Counterweight 45 RPM adapter AC adapter
Quick Start Guide
Belt-Drive Turntable
Guide de démarrage rapide
Tourne-disque à entraînement par courroie
Kurzanleitung
Riemenbetriebener Plattenspieler
Guida rapida
Giradischi
Guía de inicio rápido
Giradiscos de tracción por correa
Guia de início rápido
Toca-discos acionado por correia
Краткое руководство по установке
Проигрыватель с ременным приводом
快速启动指南
皮带传动唱盘机
快速入門指南
皮帶驅動式黑膠唱機
간편 사용 설명서
벨트 드라이브 턴테이블
User Manual (Online Manual)
https://www.audio-technica.co.jp/document/AT-LP2022/
Default.html
Back side with hexagonal nut
Drive belt
Platter (with drive belt)
(Remove the protective sheet before use.)
Replacement stylus
Dust cover hinges Headshell with VM stereo cartridge (AT-VMN95SH CL)
Hexagonal wrench
RCA audio cable (For tonearm height adjustment)

Preparation

Use the included gloves to avoid fingerprints on the turntable.
1
With the turntable turned off, set the platter.
Motor pulley
2
Attach the drive belt to the motor pulley.
3
Level the turntable.
4
Insert the headshell into the tonearm, and remove the
cartridge's protector.
Protector
Gloves
5
Attach the counterweight to the back of the tonearm, and
slowly turn it counterclockwise (to the left).
6
Unlatch the clamp.
Clamp
7
Turn the counterweight to adjust the tonearm's balance so that
the tonearm is level when you release the headshell.
Tonearm
8
Set the tracking force gauge ring to the "0" position.
After that, turn the counterweight and the tracking force gauge
ring together counterclockwise (to the left) to the "2" position.
0
Tracking force gauge ring
9
Set the anti-skate control dial to "2", the same value as the
tracking force value.
Anti-skate control dial
2
