[Type F] - Philips 55PFL6900/F7 Service Manual

[TYPE F]

COMPONENT
-Y/VIDEO-IN
COMPONENT
-Pb-IN
COMPONENT
-Pr-IN
AUDIO(L)-IN
REAR
AUDIO(R)-IN
DIGITAL
AUDIO-OUT
(OPTICAL)
PC-RGB-IN
ETHERNET
JACK
HDMI-
CONNECTOR-1
HDMI-
CONNECTOR-2
HDMI-
CONNECTOR-3
SIDE
HEADPHONE
JACK
USB JACK
ANT-IN
SP3801 SP3802
SPEAKER SPEAKER
L-CH R-CH
CL3801
CN3105
1 4
CN3801
DIGITAL MAIN CBA UNIT
Type 1, 55PFL5901/F7,
CN3601
55PFL5901/F8
26
[Type 2, Type 3]
CN3601
26
CN3902
CN3901
WIRELESS
51
LAN MODULE
55PFL5601/F7 model has the combination of more than one
Wire Assembly and Digital Main PCB.
See the following table for more information.
Wire Assembly
Parts No.
Digital Main PCB
Part No.
CN4052
1 9
CL3105
9 1
CN651
1 1
CL3601
26
CN651
1
CL3601
1 26
CN652
1 1
CL3902
6 6
CN1101
1
1
CL3901
11-4
Type 1 Type 2
WX1A51REx313 WX1A51RJx303 WX1A51RJx303
BA51REG04012 BA51RJG04012 BA51REG04012
IR SENSOR CBA UNIT
CN4051
1 2
CL4051
1 2
CN4001
FUNCTION CBA UNIT
AC CORD
B W
CN601
POWER SUPPLY CBA
CN1201 CN1401
2 1 4 1
LCD PANEL ASSEMBLY
Type 3
2
