Creative Structures HEXADOME M Manual

HEXADOME M
Dimensions
Inside
1 m 2 m 3 m 4 m 5 m
Materials
Structure
Tubes
Ø90 mm/Ø70 mm
6082T6 Alloy
Connectors
Galvanized steel
Cabels
Stainless steel 316
Materials
Cover
Fabric Airtex white®
Weight fabric 350 grams/m
Reinforcements PVC
Certification California T19 M2/B1
-20 0C +70 0C
Fabric Stam 6002®
Weight fabric 630 grams/m
Reinforcements
Stam 6002®
Certification
California T19 M2/B1
-30 0C +70 0C
Fabric
Transparant
Weight fabric
660 grams/m
Reinforcements
PVC
Certification
California T19 M2/B1
-20 0C +70 0C
100 m
+5,35 m
11,69 m
12,02 m
Gutters
Gutter M
Connect Hexadome M
with Crossover M
Gutter M to L
2
Connect Hexadome M
with Crossover L
2
Sidewalls
Dimensions
(WxH)
Sidewall
Sidewall with door
2
Installation
Structure and cover
3
2
Dimensions
Outside
Length Width
1.080 cm 1.243 cm
3 m
2 m
1 m
(HDM)
(COM)
HDM
COM
(HDM)
(COL)
HDM
COL
570 cm
210 cm
Sidewall with windows
HEXADOME M | PRODUCTSHEET | 2021 | EN
2:00 h
Length Heigth
Heigth opening opening
535 cm 622 cm 215 cm
26°
1,51 m
1,05 m
0,59 m
0,42 m
0,99 m
1,69 m
Connect Hexadome M
(HDM)
with Hexadome M
(HDM)
Connect Hexadome M
(HDM)
with Hexadome L
(HDL)
280 cm
Dimensions
(WxH)
Door opening
in the sidewall
Sidewall with door
and windows
HDM
HDM
HDM
HDL
200 cm
| 1
