- Page 1 Hexadome L Installation Version 3.1 Hexadome L Building instructions 1 | 32 www.creative-products.nl...
-
Page 2: Box Contents
Locking pin (large) Securing ring Rope 33 m. sub profile ø90 mm - 233 cm profile ø125 mm - 277 cm ø90 mm profile ø125 mm profile Hexadome L Hexadome L Building instructions Building instructions 2 | 32 3 | 32 www.creative-products.nl... - Page 3 CS-0546 T-Connector Upper Right Marked with “UR” CS-0545 Securing ring Locking pin Securing ring Locking pin CS-0248 Short version CS-0248 Short version CS-0093 CS-0093 Hexadome L Hexadome L Building instructions Building instructions 4 | 32 5 | 32 www.creative-products.nl www.creative-products.nl...
- Page 4 CS-0540 Upper X-connector CS-0541 Sub frame beam CS-0539 Hooks have to point inwards Sub frame connector CS-0558 Upper X-connector Upper main profile CS-0541 CS-0540 Hexadome L Hexadome L Building instructions Building instructions 6 | 32 7 | 32 www.creative-products.nl www.creative-products.nl...
- Page 5 Secure all parts with locking pins (long version) and securing rings Mount the sub frame at the frame body Securing ring Locking strip CS-0248 CS-0559 Hexadome L Hexadome L Building instructions Building instructions 8 | 32 9 | 32 www.creative-products.nl...
- Page 6 Do not secure yet Rotate profile clockwise to create space for assembly Upper main profile CS-0540 Lower X-connector CS-0542 Hexadome L Hexadome L Building instructions Building instructions 10 | 32 11 | 32 www.creative-products.nl www.creative-products.nl...
- Page 7 Use the two inner eyes of the X-connector Secure all parts with locking pins (long version) and securing rings Repeat this step for the other five sides Upper cable CS-0547 Hexadome L Hexadome L Building instructions Building instructions 12 | 32 13 | 32 www.creative-products.nl...
- Page 8 Mount the first end of the center cables Secure all parts with locking pins (long version) and securing rings Lower main profile CS-0536 Center cable CS-0548 Hexadome L Hexadome L Building instructions Building instructions 14 | 32 15 | 32 www.creative-products.nl...
- Page 9 (long version) and securing rings Curvature sub profiles has to point inwards When crossing other cables, place the cable above the first crossing cable and below the next crossing cable(s) Hexadome L Hexadome L Building instructions Building instructions 16 | 32 17 | 32 www.creative-products.nl...
- Page 10 Mount the second level of main profiles Secure all parts with locking pins (long version) and securing rings Lower main profile CS-0536 Tensioning cable CS-0549 Hexadome L Hexadome L Building instructions Building instructions 18 | 32 19 | 32 www.creative-products.nl...
- Page 11 Mount the second end of the center cables Secure all parts with locking pins (long version) and securing rings Curvature sub profiles has to point inwards Hexadome L Hexadome L Building instructions Building instructions 20 | 32 21 | 32 www.creative-products.nl...
- Page 12 Foot connector Left CS-0560 Foot connector Right CS-0561 Anchor slide Anchor support CS-0593 CS-0562 Secure the Anchor slides with locking pins (long version) and securing rings Hexadome L Hexadome L Building instructions Building instructions 22 | 32 23 | 32 www.creative-products.nl www.creative-products.nl...
- Page 13 After mounting the positioning cables the structure can be placed on its feet Pull the legs of the structure outwards to put the positioning cables under tension Remove the positioning cables after anchoring Hexadome L Hexadome L Building instructions Building instructions...
- Page 14 The included rope can be used to pull the cover over the structure STEP 22 Place the pull bars in the loops of the cover corners Use the inner hooks Pull bar CS-0594 Hexadome L Hexadome L Building instructions Building instructions 26 | 32 27 | 32 www.creative-products.nl...
- Page 15 Tension the contours of the cover with the turn buckles Use the seams of the cover to align the cover with the structure Ratchet plate CS-0590 Turn tensioner CS-9039 Hexadome L Hexadome L Building instructions Building instructions 28 | 32 29 | 32 www.creative-products.nl...
- Page 16 STEP 27 Mount the connection gutter (if desired) Close the zippers from right to left, seen from the inside of the structure Connection gutter CS-0270 Hexadome L Hexadome L Building instructions Building instructions 30 | 32 31 | 32 www.creative-products.nl...
- Page 17 Installation movie Lounger M Crossover M Hexadome M Installation movie Installation movie Installation movie Lounger L Crossover L Hexadome L CS BI HDL V3.1 Gewenten 43a Hexadome L 4704 RE Roosendaal Building instructions 32 | 32 The Netherlands info@creative-products.nl www.creative-products.nl T +31 (0)165 51 07 77 www.creative-products.nl...
