Creative Structures CROSSOVER M Manual

CROSSOVER M
Dimensions
Inside
1 m 2 m 3 m 4 m
Materials
Structure
Tubes Ø90 mm/Ø70 mm
6082T6 Alloy
Connectors
Galvanized steel
Cabels Stainless steel 316
Materials
Cover
Fabric Airtex white®
Weight fabric
350 grams/m
Reinforcements PVC
Certification California T19 M2/B1
-20 0C
Fabric
Stam 6002®
Weight fabric 630 grams/m
Reinforcements Stam 6002®
Certification
California T19 M2/B1
-30 0C
Fabric Transparant
Weight fabric 660 grams/m
Reinforcements
PVC
Certification California T19 M2/B1
-20 0C
38 m
+7.11
8.11
8.44
Gutters
Gutter M
Connect Crossover M
with Crossover M
Gutter M to L
2
Connect Crossover M
with Crossover L
+70 0C
2
Sidewalls
Dimensions
+70 0C Sidewall
Sidewall with door
2
+70 0C
Installation
Structure and cover
2
2
Dimensions
Outside
Length Width
622 cm 622 cm
3 m
2 m
1 m
3.24
(COM)
(COM)
(COM)
(COL)
570 cm
(WxH)
210 cm
Sidewall with windows
0:45 h
Heigth
Heigth opening
375 cm 215 cm
26°
1.07
Connect Crossover M
with Hexadome M
(HDM)
Connect Crossover M
with Hexadome L
(HDL)
Dimensions
(WxH)
Door opening
in the sidewall
Sidewall with door
and windows
CROSSOVER M | PRODUCTSHEET | 2021 | EN
1 m
(COM)
(COM)
200 cm
| 1
