Clutch Operation:

There are two positions of the clutch handle. The Clutch is
either "engaged" or "free spooling". Clutch allows
operator to manually engage or disengage the spooling
drum from the gearset using the clutch lever.
Battery Friendly Product:
Our powerful 4.8 HP series wound
motor and class leading low gear
ratios give fast line speeds with a
"Battery Friendly" low current
draw that will get the most
winching time from your battery's
available charge state.
Engaged
NEVER engage or disengage clutch
if the winch is under load, the winch
rope is under tension or the spool
is moving in any way.
18
Free Spool
