BACKEASE 600
Operators Manual
Installation, Safety, Operation, Maintenance, Guarantee.
Read these instructions fully before installing or operating
the BACKEASE 600.
Manufactured by
Heiniger Australia
5A Tayet Link
Bibra Lake, WA 6163
Tel: 08 9434 0000 Fax: 08 9434 0011
Email:
orders@heiniger.com.au
F0169 Backease Hoist Manual
Page 1 of 9
28/05/2014
Rev:03
Advertisement
Related Manuals for Heiniger BACKEASE 600
Summary of Contents for Heiniger BACKEASE 600
- Page 1 BACKEASE 600 Operators Manual Installation, Safety, Operation, Maintenance, Guarantee. Read these instructions fully before installing or operating the BACKEASE 600. Manufactured by Heiniger Australia 5A Tayet Link Bibra Lake, WA 6163 Tel: 08 9434 0000 Fax: 08 9434 0011 Email: orders@heiniger.com.au...
-
Page 2: Important Notice
Important Notice: As the installation and operation of this crane is beyond the control of the manufacturer and/or it's agents, the manufacturer and/or its agent's shall in no circumstances be liable for any loss, damage or injury of any kind whatsoever and howsoever caused or occasioned to property or persons resulting from the installation or use of this crane. - Page 3 Bolt the base to the tray using the six ½" x 2" bolts, flat and spring washers and nuts. Position the boom lugs on the closed end of the boom either side of the top of the boom post on the same side as the ram mounting lug and insert the pin. Position the lugs of the ram on either side of the lug on the boom post and insert the 1”...
- Page 4 vehicle chassis through good metal to metal contact. The vehicle chassis must be earthed to the vehicle battery. If the chassis is not earthed to the battery the power pack will try to earth through the vehicle wiring, causing damage to that wiring. Route the hydraulic hose from power pack unit, forward under the tray and up between the cab and cabguard to the hydraulic ram.
- Page 5 Operating: The boom can be raised and lowered by using the Remote Hand Control. The boom is raised by the pump generating hydraulic pressure and is lowered by the activation of the lowering solenoid allowing the weight of the boom and load to force oil out of the ram and back to the reservoir at a regulated rate.
- Page 6 Subject to and in accordance with the provisions of this Guarantee Heiniger Australia (the "Company") warrants the crane against defects in materials and manufacture for a period for twelve (12) months from the date of purchase. In the event of a defect occurring within the Guarantee period which prevents the designed or safe use of the crane the Company or its nominated representative (its "Agent") will repair or make good the defect or, at the Company's option, replace same...
- Page 7 F0169 Backease Hoist Manual Page 7 of 9 28/05/2014 Rev:03...
- Page 8 illustration 2 F0169 Backease Hoist Manual Page 8 of 9 28/05/2014 Rev:03...
- Page 9 illustration 3 illustration 4 F0169 Backease Hoist Manual Page 9 of 9 28/05/2014 Rev:03...
