  • Page 9: Chapter 1

    1260-38T User Manual Chapter 1 MODULE SPECIFICATION The 1260-38T 1 x 128 Two-Wire Scanner/Multiplexer Module Introduction consists of eight pairs of 1 x 8 multiplexers. These eight pairs of multiplexers, in conjunction with interconnecting relays, allow the 1260-38T module to be configured as:...
  • Page 10: 1260-38T Module Specification

    1260-38T User Manual Maximum Switch Power 125VA, 60W 1260-38T Module Specification Maximum Switch Voltage 250VAC, 220VDC Maximum Switch Current 2A AC, 2A DC Bandwidth (50W ) 1 x 8 Configuration >30MHz 1 x 16 Configuration >30MHz 1 x 128 Configuration >2MHz...
  • Page 11 1260-38T User Manual Temperature Operating C to+55 Non-Operating C to +71 Relative Humidity 95+1-5% RH Non-Condensing <30'C 75+1-5 %RH > 30 45+1-5 %RH > 40 Altitude Operating 10,000 ft Non-Operating 15,000ft Vibration 0.013" double amplitude, 5-55Hz Shock, functional 30g, 11msec, ½ sine wave...
  • Page 12: Ordering Information

    1260-38T User Manual Listed below are part numbers for both the 1260-38T Switch Module Ordering and available mating connector. Information Model Numbers Description Part # 1260-38T Switch Module 1260-38T, 2w, 1 x 128 sc mux, 2 amp 407410-001 160-Pin Mating Connector 160-Pin Conn.
  • Page 13: Chapter 2

    3. Reship in either the original or a new shipping carton. Installation of the Option 01 to the 1260-38T is described in the Option 01 Installation Section of the 1260 Series VXIbus Switching Cards Installation Manual.
  • Page 14: Module Installation

    Refer to Section 2 of the Series 1260 VXI Switching Card Manual for an explanation of Module ID Byte. The 1260-38T may be configured for two-wire or four wire switching. The two-wire configuration closes one relay for the selected channel. Four-wire configuration closes two relays for the selected channel.
  • Page 15: Chapter 3

    1260-38T User Manual Chapter 3 MODULE OPERATION The 1260-38T is a 1 x 128 Two-Wire Scanner/Multiplexer Module Module consisting of eight pairs of 1 x 8 multiplexers. These eight pairs of Configuration multiplexers, in conjunction with interconnecting relays, allow the...
  • Page 16: Two-Wire Operation

    Example: Make a four-wire 1 x 24 using multiplexers 00, 01, 02, 03, 04, 05 Close channels 1000 and 2000. The 1260-38T front panel connectors are labeled J200 and J201. Front Panel The connector type is 5 x 32 (160-pin) DIN 41 612 male. The pin Connectors numbering is shown in Figure 3-3.
  • Page 17: Mating Connectors

    One end is un-terminated. Refer to Table 3.1 for the mapping of channels to connector and cable. The Module Specific Syntax for the 1260-38T is required in the 1260-38T Module use of the OPEN and CLOSE commands. It will also appear in...
  • Page 18: Syntax

    1260-38T User Manual The Module Specific Syntax for the 1260-38T Multiplexer/Scanner Syntax module is as follows: <COMMAND> <relay designator> [;<relay designator>] where: <relay designator> ::= <module address>.<channel range> [,<channel range>...] <channel range> ::= <channel descriptor>[-<channel descriptor>] <channel descriptor> ::= <interconnect><mux select><channel>...
  • Page 19: Close Command

    1260-38T User Manual CLOSE Command The CLOSE command is used to close a channel. Example: CL[OSE] 1.0012 This CLOSE command will close channel 2 of multiplexer 01 on the module at switch card module address 1. The OPEN command is used to open a channel.
  • Page 20: Psetup Command

    VXI Controller. The syntax used is: PS[ETUP] <module address>[ ;<module address>] [;<module address>] Where: <module address> is the switch card address. The responses to the PSETUP command for the 1260-38T Multiplexer/Scanner is as follows: 1260-38T Two-wire <module address>. 1260-38A 1x128 2-WIRE SCANNER/MULTIPLEXER <module address>...
  • Page 21: Figure 3-1, 1260-38T Module Configuration Block Diagram

    1260-38T User Manual Figure 3-1, 1260-38T Module Configuration Block Diagram Racal Instruments © 1998 Module Operation 3-7...
  • Page 22: Figure 3-2, 1260-38T Multiplexer Configuration Block Diagram

    1260-38T User Manual Figure 3-2, 1260-38T Multiplexer Configuration Block Diagram Module Operation 3-8 Racal Instruments © 1998...
  • Page 23: Figure 3-3, 1260-38T Pin Connections, Front View

    1260-38T User Manual R a c a l In s tr u m e n ts a b c 1 2 6 0 -38 FA IL Figure 3-3, 1260-38T Pin Connections, Front View Racal Instruments © 1998 Module Operation 3-9...
  • Page 24: Table 3-1, 1260-38T Channel Number/Connector Pin/Cable Mapping

    1260-38T User Manual Table 3-1, 1260-38T Channel Number/Connector Pin/Cable Mapping Multiplexer 00 Channel # Connector Pin # Connector I Cable # I Color 0000 Hi J200P31A P200, CABLE 1, white/black/orange/violet 0000 Lo J200P32A P200, CABLE 1, white/black/yellow/grey 0001 Hi J200P31B...
  • Page 25 1260-38T User Manual Table 3-1, 1260-38T Channel Number/Connector Pin/Cable Mapping Continued Multiplexer 02 Channel # Connector Pin # Connector / Cable # / Color 0020 Hi J200P23A P200, CABLE 1, white/brown/green 0020 Lo J200P24A P200, CABLE 1, white/red/yellow 0021 Hi...
  • Page 26 1260-38T User Manual Table 3-1, 1260-38T Channel Number/Connector Pin/Cable Mapping Continued Multiplexer 04 Channel # Connector Pin # Connector / Cable # / Color 0040 Hi J200P15A P200, CABLE 2, white/black/orange/violet 0040 Lo J200P16A P200, CABLE 2, white/black/yellow/grey 0041 Hi...
  • Page 27 1260-38T User Manual Table 3-1, 1260-38T Channel Number/Connector Pin/Cable Mapping Continued Multiplexer 06 Channel # Connector Pin # Connector / Cable # / Color 0060 Hi J200P7A P200, CABLE 2, white/brown/green 0060 Lo J200P8A P200, CABLE 2, white/red/yellow 0061 Hi...
  • Page 28 1260-38T User Manual Table 3-1, 1260-38T Channel Number/Connector Pin/Cable Mapping Continued Multiplexer 08 Channel # Connector Pin # Connector / Cable # / Color 0080 Hi J201P31A P201, CABLE 1, white/black/orange/violet 0080 Lo J201P32A P201, CABLE 1, white/black/yellow/grey 0081 Hi...
  • Page 29 1260-38T User Manual Table 3-1, 1260-38T Channel Number/Connector Pin/Cable Mapping Continued Multiplexer 10 Channel # Connector Pin # Connector / Cable # I Color 0100 Hi J201P23A P201, CABLE 1, white/brown/green 0100 Lo J201P24A P201, CABLE 1, white/red/yellow 0101 Hi...
  • Page 30 1260-38T User Manual Table 3-1, 1260-38T Channel Number/Connector Pin/Cable Mapping Continued Multiplexer 12 Channel # Connector Pin # Connector / Cable # / Color 0120 Hi J201P15A P201, CABLE 2, white/black/orange/violet 0120 Lo J201P16A P201, CABLE 2, white/black/yellow/grey 0121 Hi...
  • Page 31 1260-38T User Manual Table 3-1, 1260-38T Channel Number/Connector Pin/Cable Mapping Continued Multiplexer 14 Channel # Connector Pin # Connector / Cable # I Color 0140 Hi J201P7A P201, CABLE 2, white/brown/green 0140 Lo J201P8A P201, CABLE 2, white/red/yellow 0141 Hi...
  • Page 32 1260-38T User Manual Table 3-1, 1260-38T Channel Number/Connector Pin/Cable Mapping Continued Interconnecting Channels Channel # Path 1000 COM 00 TO COM 02 1001 COM 01 TO COM 03 1002 COM 00 TO COM 01 2000 COM 02 TO COM 04...
  • Page 33: Chapter 4

    1260-38T User Manual Chapter 4 DRAWINGS 407410-001 Final Assembly, 1260-38T................ 4-3 405100-001 PCB Assembly, 1260-38T ................ 4-4 435100-001 Schematic, 1260-38T ................4-6 Front Panel Connector Accessories 407407 160-Pin Connector Kit with backshell and pins ........4-29 407408 160-Pin Cable Assy, 6ft., 24GA.............. 4-30 407409 160-Pin Cable Assy, 12ft., 24GA............
  • Page 34 1260-38T User Manual This page was left intentionally blank. Drawings 4-2 Racal Instruments © 1998...
  • Page 35 1260-38T User Manual Racal Instruments © 1998 Drawings 4-3...
  • Page 36 1260-38T User Manual Drawings 4-4 Racal Instruments © 1998...
  • Page 37 1260-38T User Manual Racal Instruments © 1998 Drawings 4-5...
  • Page 38 1260-38T User Manual Drawings 4-6 Racal Instruments © 1998...
  • Page 39 1260-38T User Manual Racal Instruments © 1998 Drawings 4-7...
  • Page 40 1260-38T User Manual Drawings 4-8 Racal Instruments © 1998...
  • Page 41 1260-38T User Manual Racal Instruments © 1998 Drawings 4-9...
  • Page 42 1260-38T User Manual Drawings 4-10 Racal Instruments © 1998...
  • Page 43 1260-38T User Manual Racal Instruments © 1998 Drawings 4-11...
  • Page 44 1260-38T User Manual Drawings 4-12 Racal Instruments © 1998...
  • Page 45 1260-38T User Manual Racal Instruments © 1998 Drawings 4-13...
  • Page 46 1260-38T User Manual Drawings 4-14 Racal Instruments © 1998...
  • Page 47 1260-38T User Manual Racal Instruments © 1998 Drawings 4-15...
  • Page 48 1260-38T User Manual Drawings 4-16 Racal Instruments © 1998...
  • Page 49 1260-38T User Manual Racal Instruments © 1998 Drawings 4-17...
  • Page 50 1260-38T User Manual Drawings 4-18 Racal Instruments © 1998...
  • Page 51 1260-38T User Manual Racal Instruments © 1998 Drawings 4-19...
  • Page 52 1260-38T User Manual Drawings 4-20 Racal Instruments © 1998...
  • Page 53 1260-38T User Manual Racal Instruments © 1998 Drawings 4-21...
  • Page 54 1260-38T User Manual Drawings 4-22 Racal Instruments © 1998...
  • Page 55 1260-38T User Manual Racal Instruments © 1998 Drawings 4-23...
  • Page 56 1260-38T User Manual Drawings 4-24 Racal Instruments © 1998...
  • Page 57 1260-38T User Manual Racal Instruments © 1998 Drawings 4-25...
  • Page 58 1260-38T User Manual Drawings 4-26 Racal Instruments © 1998...
  • Page 59 1260-38T User Manual Racal Instruments © 1998 Drawings 4-27...
  • Page 60 1260-38T User Manual Drawings 4-28 Racal Instruments © 1998...
  • Page 61 1260-38T User Manual Racal Instruments © 1998 Drawings 4-29...
  • Page 62 1260-38T User Manual 407408 DWG. NO. REV. Drawings 4-30 Racal Instruments © 1998...
  • Page 63 1260-38T User Manual Racal Instruments © 1998 Drawings 4-31...
  • Page 64 1260-38T User Manual This page was intentionally blank. Drawings 4-32 Racal Instruments © 1998...
  • Page 65: Chapter 5

    1260-38T User Manual Chapter 5 PARTS LIST 407410-001 Final Assembly, 1260-38T................5-3 407417-001 Shipping Kit, 1260-38T ................5-3 405100-001 PCB Assembly, 1260-38T ................5-4 Front Panel Connector Accessories 407407 160-Pin Connector Kit with backshell and pins .......... 5-7 407408 160-Pin Cable Assy, 6ft., 24GA ..............5-8 407409 160-Pin Cable Assy, 12ft., 24GA ..............
  • Page 66 1260-38T User Manual This page was left intentionally blank. Parts List 5-2 Racal Instruments © 1998...
  • Page 67 1260-38T User Manual Racal Instruments © 1998 Parts List 5-3...
  • Page 68 1260-38T User Manual Parts List 5-4 Racal Instruments © 1998...
  • Page 69 1260-38T User Manual Racal Instruments © 1998 Parts List 5-5...
  • Page 70 1260-38T User Manual Parts List 5-6 Racal Instruments © 1998...
  • Page 71 1260-38T User Manual Racal Instruments © 1998 Parts List 5-7...
  • Page 72 1260-38T User Manual Parts List 5-8 Racal Instruments © 1998...
  • Page 73 1260-38T User Manual Racal Instruments © 1998 Parts List 5-9...
  • Page 74 1260-38T User Manual This page was left intentionally blank. Parts List 5-10 Racal Instruments © 1998...
  • Page 75: Chapter 6

    For worldwide support and the office closes to your facility, refer to the Support Offices section on the following page. Reshipment Use the original packing material when returning the 1260-38T to Racal Instruments for calibration or servicing. The original shipping Instructions crate and associated packaging material will provide the necessary protection for safe reshipment.
  • Page 76: Support Offices

    1260-38T User Manual Support Offices RACAL INSTRUMENTS United States (Corporate Headquarters and Service Center) 4 Goodyear Street, Irvine, CA 92618 Tel: (800) 722-2528, (949) 859-8999; Fax: (949) 859-7139 5730 Northwest Parkway Suite 700, San Antonio, TX 78249 Tel: (210) 699-6799; Fax: (210) 699-8857...
