  • Page 1 sales@artisantg.com artisantg.com (217) 352-9330 | Click HERE Find the Astronics / EADS / Racal 1260-50D at our website:...
  • Page 2 PUBLICATION DATE: FEBRUARY 18, 2003 Copyright 2001 by Racal Instruments, Inc. Printed in the United States of America. All rights reserved. This book or parts thereof may not be reproduced in any form without written permission of the publisher.
  • Page 3 Thank you for purchasing this Racal Instruments product. For this product, or any other Racal Instruments product that incorporates software drivers, you may access our web site to verify and/or download the latest driver versions. The web address for driver downloads is: http://www.racalinstruments.com/downloads...
  • Page 4 Authorization is required from Racal Instruments before you send us your product for service or calibration. Call your nearest Racal Instruments support facility. A list is located on the last page of this manual. If you are unsure where to call, contact Racal Instruments, Inc. Customer Support Department in Irvine, California, USA at 1-800-722-3262 or 1-949-859-8999 or via fax at 1-949- 859-7139.
  • Page 5 FOR YOUR SAFETY Before undertaking any troubleshooting, maintenance or exploratory procedure, read carefully the WARNINGS and CAUTION notices. This equipment contains voltage hazardous to human life and safety, and is capable of inflicting personal injury. If this instrument is to be powered from the AC line (mains) through an autotransformer, ensure the common connector is connected to the neutral (earth pole) of the power supply.
  • Page 6 This page was left intentionally blank. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 7: Table Of Contents

    User Manual 1260-50C/D Table of Contents Chapter 1 INTRODUCTION ........................1-1 1260-50C/D 200MHz Multiplexer Module ................1-1 Specifications .......................... 1-3 Ordering Information ....................... 1-6 Chapter 2 INSTALLATION INSTRUCTIONS....................2-1 Unpacking and Inspection ....................... 2-1 Reshipment Instructions ......................2-1 Option 01 Installation....................... 2-1 Module Installation........................
  • Page 8 User Manual 1260-50C/D Reshipment Instructions......................7-1 Support Offices ........................7-2 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 9 User Manual 1260-50C/D List of Figures Figure 1-1, 1260-50C/D ......................1-1 Figure 1-2, 1260-50C/D Functional Diagram................1-2 Figure 1-3, 1260-50C/D Front Panel and J200-J203 Connector Pin Configuration ....1-5 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 10 User Manual 1260-50C/D This page was left intentionally blank. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 11: Chapter 1 Introduction

    User Manual 1260-50C/D Chapter 1 INTRODUCTION 1260-50C/D The 1260-50C/D provides eight/sixteen 1 x 4 multiplexers (refer to the Functional Diagram Figure 1-2). Relays CHI9, 29,..., 159 200MHz provide for the connections between the adjacent 1 x 4 groups Multiplexer under software control. Thus, the 1260-50C/D module can be configured as multiplexers up to 1 x 39/1 x 79 size.
  • Page 12 CH153 CH33 CH113 CH72 CH152 CH32 CH112 CH71 CH151 CH31 CH111 CH70 CH150 CH30 CH110 CH49 CH129 CH89 1260-50C 1260-50D Figure 1-2, 1260-50C/D Functional Diagram Introduction 1-2 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 13: Specifications

    User Manual 1260-50C/D Specifications Minimum Option 01 Firmware Revision 24.1 User Connector Housing: Burndy MSD20PM-118 Burndy RMDX60-36D28 Contact: for RG316 Coaxial Cable 200V DC/Peak AC Maximum Switchable Voltage Resistive Load (Signal to Ground) 0.5A DC/Peak AC Maximum Switchable Current Per...
  • Page 14 3-foot or one 2-foot and one 4-foot cable.) Coax pins (P/N 602220-900) suitable for RG316 coaxial cable may be purchased separately. The 1260-50C requires 40, and the 1260-50D requires 80. To crimp coaxial pins, use crimp tool Hytool M10S-1 from Burndy.
  • Page 15 User Manual 1260-50C/D Racal Racal Instruments Instruments 1260-50C 1260-50D FAIL FAIL Figure 1-3, 1260-50C/D Front Panel and J200-J203 Connector Pin Configuration Introduction 1-5 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 16: Ordering Information

    User Manual 1260-50C/D Ordering Information Model Number Description Part Number 1260-50C 407366-001 8 1X4 50W Multiplexer 40 Channels 1260-50D 407366-002 16 1X4 50W Multiplexer 80 Channels Introduction 1-6 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 17: Installation Instructions

    3. Reship in either the original or a new shipping carton. Installation of the Option 01 to the 1260-50C/D is described in Option 01 the Installation section of the 1260 Series VXI Switching Cards Installation Manual.
  • Page 18 User Manual 1260-50C/D This page was left intentionally blank. Installation Instructions 2-2 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 19: Module Specific Syntax

    Option 01 Operating Systems at Revision levels 24.1 and above. The 1260-50C/D RF Multiplexer supports the OPEN, CLOSE, PSETUP, RESET and PDATAOUT commands. The module specific syntax for the 1260-50C/D RF Multiplexer is Syntax as follows: OPEN <module address>.<channel>[ ;<module address> . <channel>J OPEN where <module address>...

  • Page 20: Close

    VXI Controller. The syntax used is: PSETUP <module address> [ ;<module address>] [;<module address>] where <module address> is the address. The responses to the PSETUP command for the 1260-50C/D multiplexer is as follows: 1260-50C: <module address>.1260-50C, 8 (1x4) 200 MHz MULTIPLEXER MODULE <module address>.B BM...

  • Page 21: Drawings

    Chapter 4 DRAWINGS 407366-001, Final Assembly, 1260-50C................4-3 407366-002, Final Assembly, 1260-50D................4-4 405072-005, PCB Assembly, 1260-50C ................4-5 405072-006, PCB Assembly, 1260-50D ................4-6 435072, Schematic, 1260-50................... 4-7 Drawings 4-1 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 22 User Manual 1260-50C/D This page was left intentionally blank. Drawings 4-2 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 23 User Manual 1260-50C/D Drawings 4-3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 24 User Manual 1260-50C/D Drawings 4-4 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 25 User Manual 1260-50C/D Drawings 4-5 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 26 User Manual 1260-50C/D Drawings 4-6 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 27 User Manual 1260-50C/D Drawings 4-7 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 28 User Manual 1260-50C/D Drawings 4-8 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 29 User Manual 1260-50C/D Drawings 4-9 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 30 User Manual 1260-50C/D Drawings 4-10 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 31 User Manual 1260-50C/D Drawings 4-11 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 32 User Manual 1260-50C/D Drawings 4-12 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 33 User Manual 1260-50C/D Drawings 4-13 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 34 User Manual 1260-50C/D Drawings 4-14 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 35 User Manual 1260-50C/D Drawings 4-15 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 36 User Manual 1260-50C/D Drawings 4-16 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 37 User Manual 1260-50C/D Drawings 4-17 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 38 User Manual 1260-50C/D Drawings 4-18 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 39 User Manual 1260-50C/D Drawings 4-19 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 40 User Manual 1260-50C/D Drawings 4-20 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 41 User Manual 1260-50C/D Drawings 4-21 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 42 User Manual 1260-50C/D Drawings 4-22 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 43 User Manual 1260-50C/D Drawings 4-23 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 44 User Manual 1260-50C/D This page was left intentionally blank. Drawings 4-24 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 45: Parts List

    Chapter 5 PARTS LIST 407366-001, Final Assembly, 1260-50C................5-3 407366-002, Final Assembly, 1260-50D................5-3 405072-005, PCB Assembly, 1260-50C ................5-4 405072-006, PCB Assembly, 1260-50D ................5-6 407367-001, Shipping Kit, 1260-50C................5-9 407367-002, Shipping Kit, 1260-50D................5-9 List of Suppliers......................5-10 Parts List 5-1 Artisan Technology Group - Quality Instrumentation ...
  • Page 46 User Manual 1260-50C/D This page was left intentionally blank. Parts List 5-2 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 47 User Manual 1260-50C/D Parts List 5-3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 48 User Manual 1260-50C/D Parts List 5-4 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 49 User Manual 1260-50C/D Parts List 5-5 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 50 User Manual 1260-50C/D Parts List 5-6 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 51 User Manual 1260-50C/D Parts List 5-7 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 52 User Manual 1260-50C/D Parts List 5-8 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 53 User Manual 1260-50C/D Parts List 5-9 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 54 User Manual 1260-50C/D Parts List 5-10 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 55: Optional Harness Assemblies

    User Manual 1260-50C/D Chapter 6 OPTIONAL HARNESS ASSEMBLIES The following harness assemblies are used to connect Racal Instruments Model 1260-50C/D to Freedom Series Test Receiver Interfaces. Each harness documentation consists of an assembly drawing, parts list, and wire list. 407288, 1260-50C Virginia Panel, Inc. Series VP90 Interface Harness......6-3 407289, 1260-50D Virginia Panel, Inc.
  • Page 56 User Manual 1260-50C/D This page was left intentionally blank. Optional Harness Assemblies 6-2 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 57 User Manual 1260-50C/D J200 J201 Optional Harness Assemblies 6-3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 58 CON-CXL-PLG020C. J200, J201 602220-900 CON-CXL-PLG0001C. W/J200, J201 610777 TIE-CA-LKG-.062-.074 910541 POLYURETHANE CONF. COAT RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50C, VP90 21793 407288 SHEET 2 of 6 Optional Harness Assemblies 6-4...
  • Page 59 This system wirelist serves as a template for incorporating this harness assembly into the overall system wirelist. It does not in any way affect the fabrication of this harness assembly. RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO.
  • Page 60 60222Q-900 J101-6 J201-A COAX 602201- 54" CHANNEL 40 (602201-008) 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50C, VP90 21793 407288 SHEET 4 of 6 Optional Harness Assemblies 6-6...
  • Page 61 602201- 54" CHANNEL 74 (602201-008) 602220-900 J102-11 NO CONNECT J102-12 NO CONNECT RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50C, VP90 21793 407288 SHEET 5 of 6 Optional Harness Assemblies 6-7...
  • Page 62 NO CONNECT J102-16 NO CONNECT J102-17 NO CONNECT J102-18 NO CONNECT J102-19 NO CONNECT RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50C, VP90 21793 407288 SHEET 6 of 6 Optional Harness Assemblies 6-8 Artisan Technology Group - Quality Instrumentation ...
  • Page 63 User Manual 1260-50C/D Optional Harness Assemblies 6-9 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 64 CON-CXL-PLG020C J200-J203 602220-900 CON-CXL-PLG0001C. W/J200-J203 610777 TIE-CA-LKG-.062,.075 910541 POLYURETHANE CONF. COAT RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, VP90 21793 407289 SHEET 2 of 7 Optional Harness Assemblies 6-10...
  • Page 65 This system wirelist serves as a template for incorporating this harness assembly into the overall system wirelist. It does not in any way affect the fabrication of this harness assembly. RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO.
  • Page 66 602220-900 J101-5 J200-X COAX 602201-807 54" CHANNEL 34 (602201-008) 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, VP90 21793 407289 SHEET 4 of 7 Optional Harness Assemblies 6-12...
  • Page 67 602220-900 J102-10 J201-X COAX 602201-807 54" CHANNEL 74 (602201-008) 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, VP90 21793 407289 SHEET 5 of 7 Optional Harness Assemblies 6-13...
  • Page 68 602220-900 J103-14 J202-W COAX 602201- 54" CHANNEL 113 (602201-008) 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, VP90 21793 407289 SHEET 6 of 7 Optional Harness Assemblies 6-14...
  • Page 69 602220-900 J104-19 J203-X COAX 602201- 54" CHANNEL 154 (602201-008) 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, VP90 21793 407289 SHEET 7 of 7 Optional Harness Assemblies 6-15...
  • Page 70 User Manual 1260-50C/D 407290 DWG. NO. REV. Optional Harness Assemblies 6-16 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 71 602196-900 CONTACT,CXL,MINI,TTI J100-J139 610777 TIE-CA-LKG-.062-.075 GRP-110-3/4 SLEEVING,BRMDED POLY,3/4 GRP-110-1/2 SLEEVING,BRAIDED POLY,1/2 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50C, TTI 21793 407290 SHEET 2 of 6 Optional Harness Assemblies 6-17...
  • Page 72 407290 (J123) (J201) BLK AAx PN 25 Uxx-SLOT yy CABLE 407290 (J124) (J201) RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50C, TTI 21793 407290 SHEET 3 of 6 Optional Harness Assemblies 6-18...
  • Page 73 This system wirelist serves as a template for incorporating this harness assembly into the overall system wirelist. It does not in any way affect the fabrication of this harness assembly. RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO.
  • Page 74 602220-900 J124 J201-E COAX 500295 40" CHANNEL 44 602196-900 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50C, TTI 21793 407290 SHEET 5 of 6 Optional Harness Assemblies 6-20...
  • Page 75 602220-900 J139 J201-X COAX 500295 40" CHANNEL 74 602196-900 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50C, TTI 21793 407290 SHEET 6 of 6 Optional Harness Assemblies 6-21...
  • Page 76 User Manual 1260-50C/D Optional Harness Assemblies 6-22 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 77 602196-900 CONTACT,CXL,MINI,TTI J100-J179 610777 TIE-CA-LKG-.062-.075 GRP-110-3/4 SLEEVING,BRAIDED POLY,314 GRP-110-1/2 SLEEVING,BRAIDED POLY,1/2 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, TTI 21793 407290-002 SHEET 2 of 10 Optional Harness Assemblies 6-23...
  • Page 78 407290- (J123) (J201) BLK AAx PN 25 Uxx-SLOT yy CABLE 407290- (J124) (J201) RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, TTI 21793 407290-002 SHEET 3 of 10 Optional Harness Assemblies 6-24...
  • Page 79 407290- (J148) (J202) BLK AAx PN 50 Uxx-SLOT yy CABLE 407290- (J149) (J202) RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, TTI 21793 407290-002 SHEET 4 of 10 Optional Harness Assemblies 6-25...
  • Page 80 407290- (J173) (J203) BLK AAx PN 75 Uxx-SLOT yy CABLE 407290- (J174) (J203) RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, TTI 21793 407290-002 SHEET 5 of 10 Optional Harness Assemblies 6-26...
  • Page 81 This system wirelist serves as a template for incorporating this harness assembly into the overall system wirelist. It does not in any way affect the fabrication of this harness assembly. RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO.
  • Page 82 602220-900 J124 J201-E COAX 500295 40" CHANNEL 44 602196-900 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, TTI 21793 407290-002 SHEET 7 of 10 Optional Harness Assemblies 6-28...
  • Page 83 602220-900 J148 J202-K COAX 500295 40" CHANNEL 93 602196-900 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, TTI 21793 407290-002 SHEET 8 of 10 Optional Harness Assemblies 6-29...
  • Page 84 602220-900 J173 J203-R COAX 500295 40" CHANNEL 143 602196-900 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, TTI 21793 407290-002 SHEET 9 of 10 Optional Harness Assemblies 6-30...
  • Page 85 602220-900 J179 J203-X COAX 500295 40" CHANNEL 154 602196-900 602220-900 RACAL Instruments, Inc., 4 Goodyear ST. Irvine CA 92718 DOCUMENT TITLE SIZE CODE NO. DOCUMENT NO. HARNESS ASSEMBLY, 1260-50D, TTI 21793 407290-002 SHEET 10 of 10 Optional Harness Assemblies 6-31...
  • Page 86 User Manual 1260-50C/D This page was left intentionally blank. Optional Harness Assemblies 6-32 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 87: Chapter 7 Product Support

    For worldwide support and the office closes to your facility, refer to the Support Offices section on the following page. Reshipment Use the original packing material when returning the 1260-50C/D to Racal Instruments for calibration or servicing. The original Instructions shipping crate and associated packaging material will provide the necessary protection for safe reshipment.
  • Page 88 User Manual 1260-50C/D Racal Instruments, Inc. Support Offices 4 Goodyear St., Irvine, CA 92618-2002 Tel: (800) RACAL-ATE, (800) 722-2528, (949) 859-8999; FAX: (949) 859-7139 Racal Instruments, Ltd. 480 Bath Road, Slough, Berkshire, SL1 6BE, United Kingdom Tel: +44 (0) 1628 604455; FAX: +44 (0) 1628 662017 Racal Systems Electronique S.A.
  • Page 89 User Manual 1260-50C/D REPAIR AND CALIBRATION REQUEST FORM To allow us to better understand your repair requests, we suggest you use the following outline when calling and include a copy with your instrument to be sent to the Racal Repair Facility.

This manual is also suitable for:
