Colordreamer Titan A8 Pro Manual page 5

Connectivity
(Titan A8)
A: LED Outputs
C: Push/Dial button
E: Status LED for Ethernet Link
G: RJ45 Ethernet thru port
J: Power Socket
Description of Status LED:
E: Status LED for Power
Status
Powered Off
Permanently Green:
D: Status LED for Ethernet Link
Status
Powered Off
www.colordreamer.com
Products and specifications are subject to change without notice
A B
B: Oled Screen
D: Reset Button
F: RJ45 Ethernet in Port
H: Status LED for Ethernet Activity
Description
Power cable not connected. The device has no power
Connected to Power. Power is on.
Description
Ethernet not connected
