Product Overview
Pixel Driver 1200 Titan A8 Pro is an eight universe Artnet to DMX driver designed for any DMX
Pixel Products. It has an integral 1200W 24VDC power supply for up to eight outputs based
upon eight universes received via Art-Net
Each output can provide maximum 150W+512DMX channels to LED Fittings.
Adjust settings and address via the onboard oled screen menu or web browser.
Perfect synchronization between each Universe.
Take full advantage of pixel mapping and voxel mapping, easy to install.
The Artnet controller device is ready within seconds after start-up. An HTP Merge is
automatically available for two Art-Net sources. If required, you can access and change
specific device settings using the built-in web configuration tool.
Product Specification
Models
Electrical
Input Voltage
Power Consumption
Control
Network Protocols
Outputs
Ethernet
Default IP
Default Subnet
Physical
Housing Material
Finish Color
Connector
Dimensions(LXWxH) Body
Dimensions(LXWxH)Brackets 483×300x88mm(2U)
Weight
Environment
Operating Temperature
Storage Temperature
Humidity
IP Rating
Certification
Warranty
www.colordreamer.com
Products and specifications are subject to change without notice
TITAN A8 Pro
90-132VA/180-264VC by switch
1200W
(8 Output, Max 150W for each output)
Art-Net via ethernet
DMX+24VDC
RJ45
192.168.1.100
255.255.255.0
Aluminium
Black
Removable Multi-pin terminal blocks
440×300x88mm
-10℃ to +50℃
-20℃ to +70℃
0-80% non-condensing
Dry, Indoor IP20
CE
2Years Limited Warranty from the Date of Manufacture
Contact us if you need extended warranty
Email:info@colordreamer.com
Version:V1.0 Feb 2022
