VOL-078
Wall Mounted Volleyball Posts
C/W Stainless Steel Winch
* Net sold separately
2 people are recommended for this assembly
30
mins
Estimated 30 minutes assembly time.
HINT: To work out the length of the net required; measure wall to wall
where the posts are mounted and subtract 1m.
i
IMPORTANT: Please read these assembly instructions carefully before
starting to assemble your Volleyball Posts.
IMPORTANT: To attach your posts to the wall you will need to fit
i
appropriate wall and floor fixings (fixings supplied are for solid wall
types only)
INS078
Revision 0
24/05/2017
