- Page 1 U S A G E A N D C A R E G U I D E PRODUCT CODE: ECT60G4X...
- Page 2 Preface Thank you for choosing our gas cooktop. To use this appliance correctly and prevent any potential risk, read these instructions before using the appliance. Keep these instructions in a place where you can find them easily. If you are unsure of any of the information contained in these instructions, please contact our customer care centre.
-
Page 3: Table Of Contents
Contents Preface Safety Warning Safety Instructions Installation Child and People Safety During Use Cleaning and Service Environmental Information Instructions for use and maintenance Description of the appliance How to Use the appliance Safety and Energy saving advice Cleaning and Maintenance Technical instructions Using instructions Positioning... -
Page 4: Safety Instructions
Safety Instructions Please take the time to read this Instruction Manual before installing or using the appliance. This instruction booklet must be kept with the appliance for any future reference. If the appliance is sold or transferred to another person,ensure the booklet is passed on to the new user. -
Page 5: Installation
Installation Warning This appliance shall be installed in Prior to installation,ensure that the accordance with regulations in force gas and electrical supply complies and only used in a well ventilated with the type stated on the rating space. plate. 220V-240V Do not use this appliance as a The gas pipe and electrical cable space heater. -
Page 6: Child And People Safety
Child and People Safety Warning Do not allow children to play near or with the appliance. The appliance gets hot when it is in use. Children should be kept away until it has cooled. Caution ■ This appliance is designed to be operated by adults. ■... -
Page 7: During Use
During Use Warning Burner ■ Only use the appliance for preparing panel is not designed to operate from food. an external timer or separate remote control system. The use of a gas cooking appliance ■ Do not use this appliance if it comes results in the production of heat and in contact with water. - Page 8 Danger of fire: Do not store items on the cooking surface this appliance while it is in operaiton. ‘ ’ position when not in use. Caution pots or pans. the appliance surfaces of the cooking appliance. Do not use a tea towel or similar materials in place of a pot holder.Such cloths can catch fire on a hot burner.
-
Page 9: Cleaning And Service
Cleaning and Service Warning ■ This appliance should only be repaired ■ Never use abrasive or caustic cleaning or serviced by an authorised Service agents. Engineer and only genuine approved spare parts should be used. Caution ■ Before attempting to clean the appliance, it should be disconnected from the mains and cooled. -
Page 10: Description Of The Appliance
Description of the appliance Dimension Ignition Electric Burner Nominal Gas Top Plate supply (W*D*H) device Connection Feature Consumption Continuous 220-240Vac, Triple-Crown(1), Stainless 590*510*90 Ignition G1/2 thread 50Hz-60Hz, Semi-rapid(2), Steel 30.4MJ/h Type Auxiliary (1) - Page 11 Description of the appliance Accessories Sponge (4) Pressure regulator (1) Bracket (4) Pressure joint(1) Screw (4) Instruction Elbow (1) Manual (1) How to use the Appliance The following symbols will appear on the control panel, next to each control handle : Black circle: gas off Large flame: maximum setting Small flame: minimum setting...
-
Page 12: How To Use The Appliance
How to Use the appliance Automatic ignition with flame failure safety device The appliance is fitted with a flame failure safety device on each burner, which is designed to stop the flow of gas to the burner head in the event of the flame going out. -
Page 13: Safety And Energy Saving Advice
Safety and Energy saving advice - The diameter of the bottom of the pan should correspond to that of the burner. PANS BURNERS max. min. Triple-Crown 200mm 240mm of the Rapid 200mm 240mm burner. Semi-Rapid 160mm 180mm Auxiliary 120mm 160mm Do not use small diameter cookware on large Always use cookware that is burners. -
Page 14: Cleaning And Maintenance
Cleaning and Maintenance completely cool. you should clean it using water and a little washing up liquid. Metal Brush Nylon Brush Soft cloth Acidic/Alkali Edible Oil Detergent Neutral Detergent Abrasive Thinner/Benzene ■ Take off the Pan support. ■ Clean these and the control handles with a damp cloth, washing up liquid and warm water. - Page 15 Cleaning and Maintenance ■ Remove the burner lids and Flame Spreaders by pulling them upwards and away from the top plate. ■ Soak them in hot water and a little detergent or washing up liqui. ■ After cleaning and washing them, wipe and dry them carefully. Make sure that the flame holes are clean and completely dry.
-
Page 16: Using Instructions
sing instructions Warnings be installed and connected in accordance with current appliance installation life hob. This appliance is not suitable for use with aftermarket lids or covers. - Page 17 CLEARANCES REQUIRED WHEN FITTING THE HOB WITH A COOKER HOOD ABOVE 650mm 400mm 400mm FO 0813 This appliance is to be built into a kitchen unit or 600mm worktop,providing the following minium distances are allowed; 650 mm between the highest point of the hob surface (including the burners) and the underside of any horizontal surface directly above it.
-
Page 18: Installing The Appliance
Installing the appliance Remove the pan supports, the burner lid and flame spreader and carefully turn the appliance upside down and place it on a cushioned mat. Take care that the Ignition devices and flame supervision devices are not damaged in this operation. -
Page 19: Gas Connection
Gas Connection Turn off power for safety and appliance protection. Close middle valve to prevent gas leakage. Keep away from inflammable materials around appliance. Before work, put on gloves. CAUTION Cool off the appliance for a while right after using appliance for your safety because you can get burners by high temperature from the appliances. - Page 20 Gas onnection Statutory requirements This installation must conform with the following: ■ Manufacturer’s Installation instructions ■ Local Gas Fitting Regulations ■ Municipal Building Codes ■ Refer to AS/NZS 5601.1 for Gas Installations ■ AS/NZS 3000 - Wiring Rules ■ Local Electrical Regulations ■...
- Page 21 Gas Connection ■ Flexible Hose: If installing with a hose assembly, it must comply with AS/NZS 1869,10mmID,class B or D,no more than 1.2m long and installed in accordance with AS/NZS 5601.1. ■ Ensure that the hose does not contact the hot surfaces of the hotplate,oven,dishwasher or any other appliance that may be installed underneath or next to the hotplate.The hose should not be subjected to abrasion, kinking or permanent deformation and should be able to be inspected along its...
-
Page 22: Gas Specifition
Gas Specification Heat input and orifice size marked(mm) Gas type & pressure Semi-rapid Wok burner Rapid burner Auxiliary 13.5MJ/h 4.3MJ/h 10.8MJ/h 6.3MJ/h Universal LP Gas 1.00 0.68 0.58 2.75kPa Natural Gas 1.72 1.15 0.93 1.0kPa... - Page 23 - Green/yellow = Earth - Blue = Neutral - Brown = Live It is necessary to allow disconnection of the appliance from the supply after installation. The disconnection can be achieved by having the plug accessible or by incorporating a switch in the fixed wiring in accordance with the wiring rules.
-
Page 24: Gas Adjustment
Gas adjustment Change the injector of the burners. Remove the pan support, Burner lid and Flame spreader. Unscrew the injector using a 7mm box spanner and replace it with the stipulated injector for new gas supply. Carefully reassemble the all components. After injectors are replaced, it is advisable to strongly tighten the injector in place. -
Page 25: Trouble Shooting
Trouble shooting Repairs should be performed by a licensed technician only.Improper repair may result in considerable danger to you and others. ■ However, some minor problems can be resolved as follows : Probable cause Solution Problem No Spark. Check the electricity supply. Not ignited The burner lid is badly assembled. - Page 26 Warranty Subject to the exclusions and limitations set out below we warrant to you that if you purchase Euro Appliances from one of our authorised retailers that they will not contain defects as a result of faulty manufacturer workmanship or materials.
- Page 27 Pronto Service + Support: 1800 440 335 Email: service@eurostylegroup.com.au HEAD OFFICE 65 Glynburn Road, Glynde SA 5070 Ph: 08 8165 1012 www.euroappliances.com.au...
