CyberData SIP IP66 Installation Quick Reference

RTFM Switch
RTFM Access
The RTFM switch access will be on the top side of the horn hidden under a screw that will be used to keep the unit IP66
sealed with the gasket washer. To access the RTFM, complete the following steps:
1. Remove the RTFM cover screw to gain access to the RTFM switch (see the figure below).
2. Use a paper clip to feed through the hole to press the RTFM switch (see the figure below).
Announce the IP Address
To broadcast the device's current IP address, press and hold the RTFM switch for a couple of seconds and then release
it.
Restore the Factory Default Settings
To restore the factory defaults, complete the following steps:
1. Press and hold the RTFM switch until you hear the device announce the words, "restoring defaults" and "rebooting".
2. Release the RTFM switch. The device will be restored to the factory default settings.
RTFM
Cover Screw
Contacting CyberData
Corporate Headquarters
CyberData Corporation
Sales: 831-373-2601 ext. 334
3 Justin Court
Support: 831-373-2601 ext. 333
Monterey, CA 93940, USA
Support Website:
RMA Department Contact and Status:
Phone: 831-373-2601
Warranty Information:
Fax: 831-373-4193
https://www.cyberdata.net/
© 2022, CyberData Corporation, ALL RIGHTS RESERVED
Paper Clip
1.0" [25 mm]
Dimensions are in Inch [Millimeters]
https://support.cyberdata.net/
https://support.cyberdata.net/
https://support.cyberdata.net/
931958A Quick Reference
Installation Quick Reference
The IP Endpoint Company
SIP IP66 Indoor/Outdoor Horn
011457
Parameter
IP Addressing
a
IP Address
Web Access Username
Web Access Password
a
Subnet Mask
a
Default Gateway
a. Default if there is not a DHCP server present.
Typical System Installation
802.3at Compliant PoE Switch
SIP IP66 Outdoor Horn
Getting Started
• Download the Operations Guide PDF file from the Documents tab at the following webpage:
https://www.cyberdata.net/products/011457
• Create a plan for the locations of your paging amplifiers.
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: The SIP IP66 Indoor/Outdoor Horn enclosure is not rated for any AC voltages!
Parts
Quick Reference
Factory Default Setting
DHCP
192.168.1.23
admin
admin
255.255.255.0
192.168.1.1
*See the Operations Guide for more
installation options.
VoIP Phone IP-PBX Server
(1) Assembly
931958A © 2022, CyberData Corporation, ALL RIGHTS RESERVED
