- Page 1 Toby INSTRUCTIONS www.dunelm.com...
- Page 2 Thank you Dear Customer Thank you for purchasing your new piece of furniture from Dunelm. We put a lot of effort in the design and construction of our products to ensure they set the standard for quality, durability and ease of assembly.
- Page 3 Component parts supplied Dimensions Visual (mm) 1830x504x16 1830x504x16 1830x504x16 731x504x16 731x504x16 1737x369x5 731x70x16 432x70x16 1766x371x16 www.dunelm.com...
- Page 4 Parts and fittings Φ Φ 26pcs 15x13.5 28pcs 8x30 28pcs M6x40mm M4x20mm 8pcs 4pcs 29.5x23x19 16pcs 60x17x10 4pcs 2pcs L=723mm M4x16 24pcs Φ Hinge 28pcs 16pcs 2pcs L=1727mm 2set www.dunelm.com...
- Page 5 Exploded view www.dunelm.com...
- Page 6 Step 1: 7 x2 CORRECT WRONG M6x40mm 4pcs Φ 15x13.5 4pcs Step 2: M6x40mm 10pcs Φ 15x13.5 10pcs www.dunelm.com...
- Page 7 Step 3: Φ 15x13.5 4pcs M6x40mm 4pcs Φ 8x30 6pcs Step 4: M6x40mm 4pcs Φ 15x13.5 4pcs Φ 6pcs ΦL=1727mm 1pcs 8x30 www.dunelm.com...
- Page 8 Step 5: Φ M6x40mm 4pcs 15x13.5 4pcs Φ 8x30 6pcs Step 6: Φ M6x40mm 4pcs 15x13.5 4pcs Φ 8x30 6pcs L=1727mm www.dunelm.com...
- Page 9 Step 7: 6 x4 16pcs 29.5x23x19 16pcs M4x16 Step 8: !!Notice!! Please make sure all fittings are locked before setting the wardrobe upright. www.dunelm.com...
- Page 10 Step 9: If necessary, gently adjust the top panel(4#) sideways in either direction until XX and YY are equal. Step 10: L=723mm 2pcs 4pcs 60x17x10 M4x16 8pcs www.dunelm.com...
- Page 11 Step 11: 13 x4 Hinge 16pcs www.dunelm.com...
- Page 12 Step 12: high hinge low hinge high hinge low hinge H i nge 16pcs M4x20mm 8pcs 4pcs www.dunelm.com...
- Page 13 Step 13: Adjust the Adjust the Adjust the up front and back left and right and down gap gap through gap through through screw screw screw Step 14: Add the screw Φ20 28pcs covers for those visible cams www.dunelm.com...
- Page 14 Step 15: Fixing wardrobe to the wall www.dunelm.com...
- Page 15 Move the wardrobe closer to the wall, and pass at end of the cable tie through the plastic bracket on the wall, then fix the other on the back of the wardrobe side. Insert the at end of the cable tie into the buckle of the cable tie, then tighten the cable tie. www.dunelm.com...
- Page 16 Please ensure that the head of the screws used has a diameter greater than the diameter of the hole on When drilling into the walls, always ensure there are no hidden wires or pipes. www.dunelm.com...
- Page 17 Wall xings www.dunelm.com...
- Page 18 Always follow fitting instructions carefully and retain them for future use. Always lift your furniture into place, avoid dragging it across the floor as this can cause damage to joints. Protectors are securely fitted and in place. www.dunelm.com...
