Summary of Contents for Dunelm Soho 4 Drawer Chest
- Page 1 PRODUCT DESCRIPTION Soho 4 Drawer Chest, 90x40x95cm, high gloss PU finish White.
-
Page 2: Dear Customer
DEAR CUSTOMER Thank you for purchasing your new piece of furniture from Dunelm. We put a lot of effort in the design and construction of our products to ensure they set the standard for quality, durability and ease of assembly. - Page 3 Parts & Fittings for Soho 4 Drawer Chest (30213106) Panel - exploded view Panels - plan view Top panel(90x40cm) Bottom panel(90x40cm) Front rail (84.7x7.6cm) Left side panel Right side panel Back rail (85x39.9cm) (85x39.9cm) (84.7x7.6cm)
- Page 4 15mm Screw x68 Plastic Bracket x4 340mm Plastic Cable Tie x2...
-
Page 5: Tools Required
350mm Runner x8 Leg x4 28mm Connecting bolt x4 13mm Locking cam x4 Tools required Cross slot screwdiver Hammer Tape measure The use of power tools to assemble the product is not recommended due to the risk of over tightening ÿxings . Before you start Check the pack and make sure you have all the parts listed above. - Page 6 Note: Please place panel on a soft surface like a carpet to avoid scratches. Note: Please place panel on a soft surface like a carpet to avoid scratches. This end to the front edge of the panel front edge Slot Outlet Fully insert locking cams on the boards,...
- Page 7 Note: Please place panel on a soft surface like a carpet to avoid scratches. This end to the front edge of the panel Front edge Slot Top edge Outlet Fully insert locking cams on the boards, Screw connecting the slot always points bolts as far as shown to the outlet of holes.
- Page 8 Note: Please place panel on a soft surface like a carpet to avoid scratches. Fit the panels together with help. Fit the panels together with help.
- Page 9 Back edge Fit the panels together with help. Note: Please place panel on a soft surface like a carpet to avoid scratches. Screw connecting bolts as far as shown Do not over tighten.
- Page 10 Two people required to turn over the unit carefully. Fit the panels together with help. Note: Maintain the cabinet alignment when fixing XX=YY Ensure cabinet is in square before fitting back panel...
- Page 11 Fixing unit to the wall a. With help, move unit into position. remove the unit. plastic bracket to the wall. Turn cable tie so that the smooth bracket side is facing upward. bracket on the wall on the wall through the plastic bracket underneath top panel 1 and the slot in the upper back panel 13 .
- Page 12 Low edge (With Groove) Slot Outlet Fully insert locking cams on the boards, the slot always points to the outlet of holes.
- Page 13 Nearly There! Align the drawers as shown. Fit both drawer slides into drawer tracks straight and evenly, not tilting to one side. Please make sure both left and right slides are engaged at the same time.
- Page 15 Remove the drawers Press the plastic clips on both drawer slides helped with a screwdriver. Detach the drawer slides from drawer tracks Pull out the drawer straight and evenly, not tilting to one side.
- Page 16 Wall Fixings Strap Base x4 340mm Wall strap x2 and we recommend that once in position the unit is secured to the wall for extra stability. • Please ensure that the head of the screws used has a diameter greater than the diameter of the hole on •...
- Page 17 For use with plaster board tting in this case. For light partitions or hollow loads, a General Purpose Plug wooden doors. can be used. dunelm.com...
-
Page 18: Care And Maintenance
From time to time check that there are no loose screws on this unit. This product should not be discarded with household waste. Take to your local authority waste disposal centre. Finally, we hope you enjoy your furniture for many years to come and thanks again for your purchase. dunelm.com...
