Product Training
V810A
P a s s i o n f o r I n n o v a t i o n
V1.3, January 4, 2023

Advertisement

loading
Need help?

Need help?

Do you have a question about the V810A and is the answer not in the manual?

Questions and answers

Related Manuals for Atel V810A

Summary of Contents for Atel V810A

  • Page 1 Product Training V810A P a s s i o n f o r I n n o v a t i o n V1.3, January 4, 2023...
  • Page 2 ATEL OVERVIEW WE ARE THE BIGGEST AND BEST IN QUALITY ODM. WE WERE ESTABLISHED IN 2003 AND ARE ONE OUT OF 12 COMPANIES OF THE PUBLICLY TRADED STAR-NET GROUP. WE BUILD COMPLEX PRODUCTS THAT SOLVE PROBLEMS, BRINGING SIMPLE SOLUTIONS. CONFIDENTIAL – For Use Under NDA Only...
  • Page 3 The V810A Axis 1 Fixed Wireless Access Router CELLULAR LTE Cat-4 BATTERY + SECURITY Verizon Security Level 1 Approved USB Type-C Charger with 4G LTE B2/4/5/12/13/14/66/71 POWER 110-240V AC Input; 5V 2A DC Output Secure Boot 3G B2/4/5 INFORMATION Secure Firmware/software upgrade 1800mAh, 3.7V Battery Backup with...
  • Page 4 The V810A Axis 1 Diagram LCD Display Battery Port Displays Home, Device This battery port is used to Information, Hotspot login connect to a Ni-MH information, and Online Portal rechargeable battery pack (may login information. be sold separately). Power Button...
  • Page 5 The V810A Set-Up Guide Install SIM Card 1. Remove the V810 back cover. 2. Install the 4FF Nano SIM card into the spring-loaded SIM slot as the image shows. To remove a SIM, press the edge of the SIM inward and the SIM will pop outward from the SIM slot.
  • Page 6 1. Align the antenna with the antenna port and screw securely into place (in a clockwise direction). 2. Restart the V810 after the antenna is installed. Note: Antenna may be sold separately. Using optional accessories (antenna and battery pack) by ATEL are recommended, available at ATEL website, https://www.atel-usa.com/.
  • Page 7 The V810A Set-Up Guide Connect your Computer to the V810 Using the Ethernet Port The V810 provides 1 Ethernet port (RJ45). For internet access, plug an ethernet cable to the Ethernet port of your V810 and connect it to the Ethernet port of your computer.

  • Page 8: Lcd Display Icons

    The V810A LCD Display Icons CONFIDENTIAL – For Use Under NDA Only...

  • Page 9: Device Management Options

    The V810A Device Management Options The V810A Device Management Options WebGUI: Local Device Management Web Interface 2. ARMS: Remote Management Portal 3. APP: Remote Management by Phone (IOS and Android) Option 1 Example Option 2 Example Option 3 Example CONFIDENTIAL – For Use Under NDA Only...
  • Page 10 The V810A Device Management Option 1 Management Option Management Instructions Connect your PC and V810 device using WiFi from the device, ethernet cable or USB-C cable. Using your Web Browser, visit 192.168.0.1 WebGUI (Local Device Log in to the WebGUI. Your Username is ‘admin’ and password can be found on the LCD display or on Management Web Portal) the device label on the bottom of the device (under the battery cover).
  • Page 11 You can register with an “Admin” account without the device information (note that you must have an agreement ready with ATEL first.) Admin accounts can manage all the devices ATEL preload for you. ARMS (Remote Device The registered account can be used to log-in to ARMS and the APP.
  • Page 12 The V810A Device Management Option 2 Device List Example support@atel-usa.com support@atel-usa.com CONFIDENTIAL – For Use Under NDA Only...
  • Page 13 The V810A Device Management Option 2 Dashboard Example support@atel-usa.com CONFIDENTIAL – For Use Under NDA Only...
  • Page 14 The V810A Device Management Option 2 Data Usage Example support@atel-usa.com CONFIDENTIAL – For Use Under NDA Only...
  • Page 15 The V810A Device Management Option 2 Settings Example support@atel-usa.com CONFIDENTIAL – For Use Under NDA Only...
  • Page 16 ARMS, you can use the same credentials to log in. You can register with an “Admin” account without the device information (note that you must have an agreement ready with ATEL first.) Admin accounts can manage all the devices ATEL preload for you. APP (Remote Device Management by The registered account can be used to log-in to ARMS and the APP.
  • Page 17 The V810A Device Management Option 3 Device List Example Device Info Example Device Settings Example CONFIDENTIAL – For Use Under NDA Only...
  • Page 18 For more information: @AsiatelcoUSA @atel-asiatelco @ATEL USA @ATEL_USA CONFIDENTIAL – For Use Under NDA Only...
  • Page 19 ssurance THANK YOU echnology Innovation P a s s i o n f o r I n n o v a t i o n ngagement...
