When a subframe is
created, it is best to
specify an image type
for the new subframe
that is different from the
main frame or other
subframes that will be
created after it.
In the chart, for
instance, if the main
frame has an image
type of "Photo" and with
a scan type of "RGB
Color" or "Grayscale",
the recommended
subframe is "Text".

Frame Settings

Allows you to set different frame settings. The options for frame property settings
include: Attribute, Coordinate Position (X, Y), Image Size (W, H), Unit of
Measurement, Image Correction tools, Default button, and Advanced buttons.

Attribute

The Attribute allows you to select the image type of the selected frame. Options
include Photo, Line Art, and Text.
Photo Photo images are image originals that use three colors (Red, Green, and
Blue), or are grayscale images.
Line Art Line art images are made up of one bit of color (black or white) per
pixel. Few editing options are available in this mode, but this mode is
useful for images consisting purely of black and white or even single
colors, such as mechanical drawings, blueprints, or fine-line
illustrations.
Text Text image originals can be RGB Color, Grayscale, or Black & White
images. If your text image original is Black & White, you may select
Black & White in the Scan Type options menu. If the text image original
is Color or Grayscale, specify the same settings (i.e., Color or
Grayscale) in the Scan Type options menu.
Original
Scan Type
Attribute
of Main Frame
Line Art
Text
Line Art
RGB Color Grayscale
Photo Photo
Text Text
Photo Photo
18
Text
Black-and-White
Line Art
