  • Page 1 Z-EMAP66 Series MOTOR HOMES INFOTAINER NAVIGATION USER MANUAL...

  • Page 2: Table Of Contents

    Table of contents 1 Getting started ......................5 1.1 Initial set-up ........................5 1.2 Screen controls ....................... 6 1.2.1 Using the buttons and other controls..................6 1.2.2 Using the cursor ........................8 1.2.3 Using the keyboard ......................8 1.2.4 Using touch gestures ......................9 1.2.5 Manipulating the map ......................
  • Page 3 3.1.6 Selecting a saved route ...................... 42 3.1.7 Entering coordinates ......................42 3.1.8 Selecting a location on the map ..................44 3.1.9 Planning a Multipoint Route ....................45 3.2 Checking route information and alternatives .............. 46 3.3 Checking Traffic Events ....................47 3.4 Editing the route ......................
  • Page 4 4.3.1 Route preferences settings ....................68 4.3.1.1 Route Planning Method types ....................68 4.3.1.2 Navigation Mode ........................69 4.3.1.3 Road types ..........................69 4.3.2 Sound settings ........................70 4.3.3 Warnings settings ....................... 72 4.3.4 Navigation View settings ....................72 4.3.5 Regional settings ........................ 74 4.3.6 Display settings ........................

  • Page 5: Getting Started

    1 Getting started ZENEC is optimised for in-car use. You can use it easily by tapping the screen buttons and the map with your fingertips. When you start using the product, you can download new maps in the next. 1.1 Initial set-up When using the navigation software for the first time, an initial set-up process starts automatically.

  • Page 6: Screen Controls

    1.2 Screen controls The following sections describe the functionality and use of buttons, sliders, and other screen controls in ZENEC. 1.2.1 Using the buttons and other controls To operate ZENEC, tap the buttons on the touch screen. Type Example Description...
  • Page 7 You need to confirm selections or changes only if the application needs to be restarted, if it needs to perform a major reconfiguration, or if you are about to lose some of your data or settings. Otherwise, ZENEC saves your selections and applies the new settings without confirmation as soon as you use the controls.

  • Page 8: Using The Cursor

    1.2.2 Using the cursor You can select a map location in the following ways: • By tapping the map when navigating • By tapping the map when you are asked to confirm the destination at the end of a search. When a map location is selected, the cursor ( ) appears at the selected point on the map.

  • Page 9: Using Touch Gestures

    Action Function Starting a search for a keyboard entry Hiding the keyboard 1.2.4 Using touch gestures You usually need to tap the screen only once. However, some useful features can be accessed with other gestures. See the table below. Action Function Tapping and Tap and keep pressing the following buttons to reach extra functions:...

  • Page 10: Manipulating The Map

    Change how much of the map is displayed on the and out screen. ZENEC uses maps that let you examine the locations at various zoom levels, always with optimised content. It always displays street names and other text with the same font size, never upside- down, and you only see the streets and objects that you need.
  • Page 11 Changing 2D, Switch between the 3D perspective, 2D Heading up, 3D, or 2D and 2D North up map view modes. In Heading up North up views mode the map is rotated so its top always points in the current driving direction. This is the default orientation in 3D map view mode.

  • Page 12: Navigation View

    1.3 Navigation view The navigation view is the main screen of ZENEC that shows the planned route on a map. ZENEC works with digital maps which are not simply the computerised versions of traditional paper maps. Similarly to paper road maps, the 2D mode of digital maps shows you streets and roads.
  • Page 13 GPS position The dot near the arrow shows the GPS position as perceived by the GPS receiver. See page 14. Planned route The planned route is displayed as an orange line. Data fields Three data fields show the following information: •...

  • Page 14: Streets And Roads

    When entering a tunnel, the map is replaced with a generic tunnel image. See page 18. 1.3.1 Streets and roads ZENEC shows the streets similarly to paper road maps. Their width and colours correspond to their importance; you can easily tell a motorway from a small street.

  • Page 15: Turn Preview And Next Street

    1.3.4 The planned route The planned route is the currently navigated route. Whenever the destination is set, the route is active until you delete it, reach your destination or suspend navigation. ZENEC displays the route in the following ways: Symbol...

  • Page 16: Manoeuvre Icons

    Streets and roads You can choose whether you want to use or avoid certain road types (page 68). However, when ZENEC cannot that are excluded from the navigation avoid such roads, the route includes them and shows them in a colour that is different from the route colour.

  • Page 17: Lane Information

    When navigating on multi-lane roads, it is important to take the appropriate lane in order to follow the planned route. If lane information is available in the map data, ZENEC displays the lanes and their directions using small arrows at the bottom of the map. Highlighted arrows represent the lanes and the direction you need to take.

  • Page 18: Junction View

    1.3.8 Junction view If you are approaching a motorway exit or a complex intersection and the needed information exists, the map is replaced with a 3D view of the junction. The lanes you need to take are displayed with arrows. At the top of the screen, road signs show you additional information. If you want to hide the currently displayed junction and return to the Navigation view, tap the picture.

  • Page 19: Motorway Services

    ZENEC supports the following 3D object types: Type Description 3D terrain ZENEC displays 3D hills and mountains in the Navigation view, and illustrates them by colouring and shading on the 2D map. Elevated Elevated roads are complex intersections and vertically isolated roads (such roads as overpasses or bridges) displayed in 3D.

  • Page 20: Traffic Events

    1.3.12 Traffic events Road segments affected by traffic events are displayed in a different colour on the map. The following icons may appear at the top right corner of the screen: Button Description It is displayed when traffic events are not received. It is displayed when traffic events are received but they do not affect the planned route.
  • Page 21 You can see the following menu options when you are navigating without a planned route: Button Function Select your destination by entering an address or its coordinates, or by selecting a Place, a Saved Location, or a Saved Route. You can also look up your recent destinations from the History.
  • Page 22 Delete the next waypoint or the whole route. It is displayed if there is a multipoint route. In the navigation menu, you have the following additional options: Button Function Open the Saved Locations screen where you can save a location as a favourite destination or edit a saved location.

  • Page 23: Warnings And Safety Information

    Plan the route before your departure and stop if you need to change the route. You must follow the traffic rules. If you deviate from the planned route, ZENEC changes the instructions accordingly.

  • Page 24: Using The Navigation

    3 Using the navigation By default, ZENEC calculates routes using the road network of the maps provided with the product. You can select the destination and start navigating to it right away (normal navigation) if you need a route for immediate navigation.
  • Page 25 . You can see the input field at the top of the screen. Right next to it you can see the search area, the town around which the search is carried out. The default search area is the area where you are located. For a local search, skip the next step.
  • Page 26 If necessary, tap on the right side of the list and then tap the corresponding button to narrow the list of search results by type (the number on the related icon shows the number of the matching results): • to see the list of recent destinations with a matching name or address.

  • Page 27: Selecting An Address

    Navigation view to access the Navigation menu. By default, ZENEC proposes the country and town where you are (or in case there is no valid GPS position, the country and town of the last known position). If necessary, change the country, by performing the following steps: Tap the Country field.
  • Page 28 c. Tap to open the list of results and select a country from the list. If necessary, select a new town by performing the following steps: Tap the Town or Postcode field. (optional) On the Town of Postcode screen, you can select a town from the list of suggestions.

  • Page 29: Selecting A Town Centre

    to open the list of results. Select the street from the list. A full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination. The cursor ( ) appears at the new location.

  • Page 30: Selecting The Midpoint Of A Street

    Go to , and modify the country as described earlier (page 27), if necessary. If necessary, select a new town by performing the following steps: Tap the Town or Postcode field. (optional) On the Town of Postcode screen, you can select a town from the list of suggestions.

  • Page 31: Selecting An Intersection In A Town

    (optional) On the Select Street screen, you can immediately select a street from the list of suggestions. c. Otherwise, start entering the street name on the keyboard. The names that match the string appear in a list. to open the list of results. Select the street from the list.

  • Page 32: Using The Postcode To Select A Destination

    to open the list of results. Select the street from the list. Tap the House number or crossing street field and browse the list of crossing streets or start entering the street name in the field. Select one from the list. 3.1.2.5 Using the postcode to select a destination You can also select any kind of destination by entering the postal code instead of the city name.

  • Page 33: Selecting A Place Of Interest

    3.1.3 Selecting a Place of Interest You can search for Places of Interest (Places) in the menu. Using the same screen, you can find a Place by selecting one of the following options: • Finding frequently searched types of Places with the Quick search categories, see page 33 •...
  • Page 34 Tap any of the quick search buttons to get an instant list of Places. The Places in the list can be ordered by their distance from the current or last known position, from the destination, or by the length of the necessary detour. If you need to reorder the list, tap .

  • Page 35: Searching By Category

    The route is calculated and the map appears showing the entire route, where you can check route information and route alternatives. Tap to modify the route parameters, or tap to start your journey. 3.1.3.2 Searching by category To search for Places by their categories and subcategories, perform the following steps: on the Navigation view to access the Navigation menu.
  • Page 36 (optional) If you have selected , select the town to search in. Select one of the main Place categories (for example, Accommodation), then browse the subcategories (for example, Hotel or Motel) to find your destination. You can turn the Category View off at any level to list all Places around the selected location or along the route.

  • Page 37: Searching By Name

    3.1.3.3 Searching by name To search for a Place by name, browse the various Place categories, or use the mixture of the two search types, perform the following steps: on the Navigation view to access the Navigation menu. to open the Search By Name or Category window. Select the area around which you would like to search for the Place.

  • Page 38: Finding Help Nearby

    You can search for the name of a Place in all categories by performing the following steps: . Using the keyboard, start entering the name of the Place or browse in the categories. After entering a few letters, tap to open the list of Places or Place categories with names containing the entered character sequence.

  • Page 39: Selecting A Saved Location

    • : Medical and emergency services • : Police stations • : Petrol stations Tap any of the quick search buttons to get an instant list of those types of Places. (optional) The Places in the list can be ordered by the following criteria: •...

  • Page 40: Selecting A History Item

    (optional) If needed, tap to enable the editing option so that you can rename the saved locations or delete any of them. After you have selected a saved location as the destination, a full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination.
  • Page 41 . Two of the Smart History Items are displayed in the New Route to... screen for easy access. You can select one of them as your destination. To open all the history items, tap . The list of recent destinations appears. The list begins with the three most likely destinations that are selected based on your previous routes (Smart History).

  • Page 42: Selecting A Saved Route

    3.1.6 Selecting a saved route The routes that you have saved earlier appear in a list. To select a previous route, perform the following steps: on the Navigation view to access the Navigation menu. The list of saved routes appears. If necessary, scroll the list to see earlier routes. Select a route and the Multipoint Route screen appears.
  • Page 43 You can enter the latitude and longitude values in any of the following formats: decimal degrees, degrees and decimal minutes, or degrees, minutes and decimal seconds. (optional) If necessary, tap then and enter the coordinate in UTM format. Tip! A full screen map appears with the selected point in the middle. If necessary, tap the map somewhere else to modify the destination.

  • Page 44: Selecting A Location On The Map

    The route is calculated and the map appears showing the entire route, where you can check route information and route alternatives. Tap to modify the route parameters, or tap to start your journey. 3.1.8 Selecting a location on the map To select a map location, perform the following steps: Locate your destination on the map.

  • Page 45: Planning A Multipoint Route

    The route is calculated and the map appears showing the entire route, where you can check route information and route alternatives. Tap to modify the route parameters, or tap to start your journey. 3.1.9 Planning a Multipoint Route To build your route destination-by-destination, perform the following steps: on the Navigation view to access the Navigation menu.

  • Page 46: Checking Route Information And Alternatives

    When the selected location appears on the map, tap and the list returns. If needed, you can add further intermediate destinations. To add more route points, tap or tap change the final destination. The Add to Route... menu appears again, where you can select the new route point the same way as you have set the destination before.

  • Page 47: Checking Traffic Events

    By tapping , you can check detailed information about the route. If you tap on the right side of the screen, you can narrow the route information, for example to show only motorway sections or toll roads. By tapping , your can see a list of route alternatives and select the most suitable route.
  • Page 48 To check the traffic summary, perform the following steps: On the Navigation view, tap the traffic icon in the corner (for example, ) to open the Traffic Summary screen, or tap If there is at least one significant event on the planned route, a description is displayed about the next event.

  • Page 49: Editing The Route

    to display historical traffic information. A 2D map is displayed with road segments coloured by the likely density of the traffic in the given period. The information relevant for the current period is shown when you open the screen. If necessary, you can browse the map for a better view of certain road segments.

  • Page 50: Adding An Additional Destination

    In the Navigation menu, tap The first line from the bottom is the start of the route, normally the current GPS position. Tap , select , and confirm your action at the warning message. The Change Start to... screen appears. Select the starting point of the route the same way you select a destination.

  • Page 51: Modifying The List Of Destinations

    • on the Navigation view and tap . Add a destination to your route as described on page 45. 3.4.3 Modifying the list of destinations To edit your route, perform the following steps: on the Navigation view to access the Navigation menu. In the Navigation menu, tap You have the following options on this screen: •...

  • Page 52: Deleting The Planned Route

    Type in a name and tap The route is saved and it is available in By selecting a previously saved route, ZENEC recalculates the route using the saved destination and/or the waypoints. 3.4.5 Deleting the planned route You have the following two options to delete the navigated route: •...

  • Page 53: Selecting A Route Alternative For An Existing Route

    Select one of the route alternatives and tap to return to the previous screen. ZENEC recalculates the route. Tap to start your journey. The orange line now shows the new planned route. 3.4.7 Selecting a route alternative for an existing route...

  • Page 54: Setting A Detour

    Select one of the route alternatives and tap to return to the previous screen. ZENEC replaces the original route. Tap to start your journey. The orange line now shows the new planned route. 3.4.8 Setting a detour on the Navigation view to access the Navigation menu.

  • Page 55: Pausing Guidance

    • to open the full list of roads on the planned route. Tap any of these items on the itinerary to avoid that specific road. • to avoid a part of the planned route that is right ahead of you on the itinerary.

  • Page 56: Editing A Saved Location

    (optional) Using the keyboard, you can change the name offered for the Saved Location. to save the location. To add your home and work address to the saved locations, perform the following steps: On the Navigation view, tap , and .

  • Page 57: Running A Simulation

    In Saved Locations, Home and Work cannot be renamed. To change your Note! home or work location, tap , and confirm the address change. Adding a location to the list of saved locations is described on page 55. 3.6 Running a Simulation To run a simulated navigation that demonstrates the planned route, perform the following steps: on the Navigation view to access the Navigation menu.

  • Page 58: Off-Road Navigation

    3.7 Off-road navigation When first started, ZENEC calculates routes using the road network of the maps provided with the product. If you want to disregard roads during navigation, you can switch to off-road mode, for example when driving in a desert.
  • Page 59 You can see an orange line drawn between your current position and the next destination to reach. The Turn Preview field in the top left corner shows a compass with your bearing and the distance of the next destination. When you reach the final destination, the navigation ends. If you do not want to use off-road navigation, switch back to on-road navigation by Note! tapping...

  • Page 60: Reference Guide

    See page 49. Once the destination has been selected, ZENEC calculates the route based on your preferences. These preferences are the route planning method, the vehicle type, and the road types used or avoided when calculating the route.

  • Page 61: Smart Zoom

    4.1.5 Speed limit warning Maps may contain information about the speed limits of the road segments. ZENEC is able to warn you if you exceed the current limit. This information may not be available for your region, or may not be fully correct for all roads on the map.

  • Page 62: Historical Traffic

    4.1.6 Historical traffic If statistical traffic information is stored with the map data, ZENEC can take them into account when planning a route. In normal cases, these statistics help you avoid usual traffic jams on the given day of week in the given hour but in some cases like on public holidays that fall on normal weekdays, they can be misleading.

  • Page 63: Intelligent Navigation

    The following sections describe these features. 4.1.8.1 Congestion detour on highways ZENEC may offer a detour when you slow down on a highway due to a traffic jam. The Potential congestion detour window appears and shows the length and duration of the detour.

  • Page 64: Hints Upon Detour

    4.1.8.4 Hints upon detour If you leave the planned route by exiting a motorway, ZENEC tries to guess the reason for making a detour. The Reason for detour window appears and shows available petrol stations, restaurants or other Places around the current position. Also, if there are avoidable parts of the original route ahead (like a tunnel, a toll road or a ferry), you can find them in the list, in case you want to bypass them.

  • Page 65: Where Am I

    Shows the exact sunrise and sunset times for all your route points. Shows the GPS Information screen with satellite position and signal strength information. 4.2.1 Where Am I This screen contains information about the current position (or about the last known position if GPS reception is not available).

  • Page 66: Trip Monitor

    You can also search for assistance near your current position. Tap to open a new screen for quick search and select a category. For detailed information, see page 38. 4.2.2 Trip Monitor Trip Monitor logs information about your route. You can record a new trip by tapping and stop it by tapping By tapping on the Trip Monitor screen, you can select the following options:...

  • Page 67: Settings Menu

    4.3 Settings menu You can configure the navigation settings, and modify the behaviour of ZENEC, by tapping Tap the arrows to view the content of other pages. Changing some of these settings may not have an effect in your current region if Note! the map data do not contain the required information.

  • Page 68: Route Preferences Settings

    Usually, the best selection for fast and normal cars. Results in a route with fewer turns and no difficult manoeuvres. With this option, you can make ZENEC take, for example, the motorway instead of a series of smaller roads or streets.

  • Page 69: Navigation Mode

    Per-use toll roads are pay roads where there is a per-use charge in the routes by default. If you disable toll roads, ZENEC plans the best toll- free route. ZENEC includes ferries in a planned route by default. However, a map does not necessarily contain information about the accessibility of temporary ferries.

  • Page 70: Sound Settings

    4.3.2 Sound settings You can modify the following settings: Button Function Adjust the volume of the guidance sounds (verbal instructions) or mute Adjust the volume of the non-verbal alert sounds (beeps) or mute it. Turn off the attention tone preceding verbal instructions or adjust its volume.
  • Page 71 Set whether you want an immediate announcement for the next manoeuvre after each turn, or it is enough to receive the information when the turn is near. Set the verbosity of the voice instructions, that is how much they tell and how often they speak.

  • Page 72: Warnings Settings

    You can enable and modify the following settings: Button Description ZENEC is able to warn you if you exceed the current speed limit. This information may not be available in your region, or may not be fully correct for all roads on the map.
  • Page 73 You can modify the following settings: Button Function Adjust the basic zoom and tilt levels to your needs. Three levels are available. Switch between daytime and night colour modes or let the software switch between the two modes automatically a few minutes before sunrise and a few minutes after sunset.

  • Page 74: Regional Settings

    A top-down overview of the tunnel and the remaining distance are also displayed. In certain situations, ZENEC offers a detour when there is a traffic jam on a highway. See page 63. In certain situations, ZENEC offers an alternative route when there is a traffic jam on the road.

  • Page 75: Display Settings

    You can set the measurement units and time/date format to be used. ZENEC may not support all the listed units in some voice guidance languages. By default, the time zone is taken from the map information and adjusted by your current location.
  • Page 76 30-minute delay. The blue route is a detour that is 15 minutes longer than the original route (not counting the traffic jam). If you set the Offer detour feature to 10 minutes, ZENEC recalculates the route because it saves 15 minutes, which is more than the 10 minutes you set.

  • Page 77: Trip Monitor Settings

    4.3.8 Trip Monitor settings Trip logs contain useful information about your recorded trips. You can enable and modify the following settings: Button Description Trip monitor can record statistical data of your trips. If you need these logs later, you can let the application save them automatically for you. This is not a button.

  • Page 78: Troubleshooting

    Cause: The digital map data may not include every single address. Solution 1: If the house number is not known or ZENEC cannot find it, select only the street name. This way, ZENEC will navigate you to the midpoint of the street, where you can find the exact address more easily.

  • Page 79: Disabling The Speed Limit Warning

    Issue: Some keyboard buttons are greyed out and cannot be used. Cause: ZENEC has a smart keyboard for address search, which means that only those buttons are active that can be used to type a name that is available on the map.

  • Page 80: The Map Is Hidden Behind An Image Of A Junction

    5.6 The map is hidden behind an image of a junction Issue: The map is not visible because it is hidden behind an image of a junction. Cause: If you are approaching a motorway exit or a complex intersection and the needed information exists, the map is replaced with a 3D view of the junction.

  • Page 81: Copyright Note

    6 Copyright note The product and the information contained herein are subject to change without prior notification. This manual may not, in whole or in part, be reproduced or transmitted in any form either electronically or mechanically, including photocopying and recording, without the express written consent of NNG.
  • Page 82 © Copyright 2019 RevA / copy deadline: Q4-2019...
