Color Palette (Submenu)
Color palette Description
The palette can be used to change the pseudo-color display of the
infrared image on the display. Some tune Swatches are better suited
for specific applications and can be set up as needed. The palette is
divided into rainbow, iron red, cool, white hot, black hot, five palettes.
These palettes work best with high thermal contrast and provide
additional color contrast between high and low temperatures.
Suitable selection of color palette displays the details of the target
objective better. Rainbow, iron oxide red and cold color palettes focus
on display of color. Such color palettes are very suitable for high heat
contrast and are used to improve the color contrast between high
temperature and low temperature. But the black & white and white &
black color palettes provide even linear color.
The following is the image of the same object with selection of
different color palettes.
5 5
Rainbow Iron oxide red Cold color
5 5
White heat
Black heat
Selecting Color Palette
As shown in the figure, press "
menu
and select "
enter the color palette list. Press "
navigation to select the color palette. Then press "SELECT/ENTER"
key to
select the color palette. Press "
to exit from the menu.
5
Color palette
Spectra
Iron
Cool
White
Black
" key to enter the main
" (color palette) option and press "
" and "
" to return. Press "
" key to
" keys in
" key
