User Manual
IRTC600
Thermal Imaging Camera
Find Quality Products Online at:
GlobalTestSupply
www.
Introduction
Congratulations on your purchase of the Triplett
IRTC600 Thermal Imaging Camera. This instrument
is useful in many applications such as preventative
maintenance, troubleshooting of electrical and
HVAC systems, mechanical breakdowns, water leaks
and moisture buildup, heat loss from missing
insulation and faulty windows/doors, automotive
repair, and other places to find leaks and hot spots.
With proper care the instrument will last for many
years of accuracy and service.
Safety
Please read the safety information carefully before attempting to
operate the meter. Failure to do so could cause personal injury
or damage to the meter. Please read this manual carefully to
ensure safe and correct use.
Do not attempt to repair this device:
Please contact Triplett Technical Support for any issues
Product Support
Triplett Test Equipment & Tools
Considerations
Please observe the following guide in order not to damage the
product:
try to dismantle, assemble, or remodel any part of the
product. Repair of the product should be made by
technical personnel designated by Triplett service
technicians only.
.com
sales@GlobalTestSupply.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Triplett IRTC600
Summary of Contents for Triplett IRTC600
- Page 1 Failure to do so could cause personal injury or damage to the meter. Please read this manual carefully to ensure safe and correct use. Do not attempt to repair this device: Please contact Triplett Technical Support for any issues Product Support Triplett Test Equipment & Tools Considerations...
-
Page 2: Charging Battery
Avoid damage to probe of the product Charging Battery **NOTE: Product Clicking Sensor is automatically calibrating for Use USB data line to charge: image, The product has built-in chargeable 26650 lithium batteries. When the product works, there is light sound of clicking When the battery level is low, the top right of the screen will display every several seconds. - Page 3 Meter and Keypad Description Specifications Model IRTC600 3.5 full angle TFT Display screen display screen Infrared image resolution 220×160 Field angle 35°×26° Visible image resolution 300,000 pixels LCD resolution 320×240 Shortest focus length 0.15M Thermal sensitivity Temperature to 300 (-4°F to 572°F) measurement range ±2 /±2%...
- Page 4 File format Micro USB 2.0 Power supply Built-in chargeable 26650 battery Working time 2-3 hours Automatic power-off time Selectable: 5 minutes/20 minutes/ not power off automatically Unit, Language, Date, Time, Information Setting command Language English, Chinese, Italian, German Product size 248mm×97mm×112.8mm Product weight 588 g...
-
Page 5: Power On/Off
Operation Maximum and Minimum Temperature Display POWER ON/OFF The highest/ and lowest temperature is shown at the bottom seconds to turn the Thermal Imaging on or off. of the screen over the image will toggle Main Display between displaying and hiding this information. After powering on the power, open the lens protection cover, the screen shows the thermal imaging status. -
Page 6: Recording Video
Recording Video Long press or pull of the image capture trigger the screen will se press the SELECT/ENTER button and video will start to be recorded. Image Alignment (Submenu) Transferring Saved Images and Video Description of Image Overlapping (Fusion) The saved images can be transferred and viewed by connecting Image overlapping makes it easier for users to understand the infrared with a computer through Micro USB. -
Page 7: Deleting Images
Video (Submenu) Images (Submenu) View video View image Press the button to 171229-105030 171229-105030 171229-105031 171229-105031 171229-105032 171229-105032 171229-105033 171229-105033 As shown in the fi keys in the navigation keys to select a video, and then press the SELECT/ENTER SELECT/ENTER to view the next video. - Page 8 Color Palette (Submenu) Selecting Color Palette Color palette Description Color palette Spectra The palette can be used to change the pseudo-color display of the Iron infrared image on the display. Some tune Swatches are better suited Cool for specific applications and can be set up as needed. The palette is White divided into rainbow, iron red, cool, white hot, black hot, five palettes.
-
Page 9: Emissivity Setting
Emissivity Setting Emissivity (Submenu) The product is provided with four types of object measurement modes: Emissivity description Matt (0.95) Semi-matt (0.85) The emissivity of the product can be adjusted from 0.01 to 1.00 with the Semi-glossy (0.60) default value of 0.95. Many common objects and materials (such as Glossy (0.30) timber, water, skin and textile fabric) can reflect the heat energy According to the characteristics of the measured objects, users may set... -
Page 10: Settings (Submenu)
If you select "self- SELECT/ENTER Settings (Submenu) Keys to select the Keys to change the SELECT/ENTER menu. -menu. exits the menu. The emissivity value of common materials Substance Thermal radiation Substance Thermal radiation Bitumen Black cloth Concrete Human skin Cement Foam Sand Charcoal dust... -
Page 11: Intensity Setting
Auto Power OFF (APO) Setting Time Setting As shown in the figure, after sele After entering the menu Select in the navigation key to enter the setting time. available are No, 5 mins or 20 minutes. Select the desire APO time with the Up or Down arrow buttons and press m and save Set time... - Page 12 T hermal Analysis Software Software Installation and Operation 1. Connect the product with a USB cable, and then connect to the computer Open the removable disk in the computer, find the "INSTALLATION PACKAGE" folder and open it, and click to install the software. 2.
-
Page 13: Icon Introduction
Software User Interface Introduction Icon Introduction 1. Select the language in the upper right corner of the interface, you can choose Chinese, English, and switch between the two languages. 1. " " icon, take the temperature of the thermal image. 2. - Page 14 Warranty Triplett / Jewell Instruments extends the following warranty to the original purchaser of these goods for use. Triplett warrants to the original purchaser for use that the products sold by it will be free from defects in workmanship and material for a period of (1) one year from the date of purchase.
