[MAIN UNIT]
REF ORDER
NO. NO.
C613 4030014180 S.CERAMIC
C614 4030014220 S.CERAMIC
C615 4030014180 S.CERAMIC
C616 4030014220 S.CERAMIC
C617 4030014220 S.CERAMIC
C618 4030014490 S.CERAMIC
C619 4030014180 S.CERAMIC
C622 4030014180 S.CERAMIC
C623 4030014490 S.CERAMIC
C624 4030014180 S.CERAMIC
C625 4030014180 S.CERAMIC
C626 4030014180 S.CERAMIC
C627 4030014180 S.CERAMIC
C628 4030014180 S.CERAMIC
C629 4030014180 S.CERAMIC
C630 4030014180 S.CERAMIC
C631 4030014180 S.CERAMIC
C632 4030014180 S.CERAMIC
C633 4030014180 S.CERAMIC
C634 4030014490 S.CERAMIC
C635 4030014490 S.CERAMIC
C636 4030014180 S.CERAMIC
C637 4030014180 S.CERAMIC
C638 4030014180 S.CERAMIC
C639 4030014180 S.CERAMIC
C640 4030014490 S.CERAMIC
C641 4030014280 S.CERAMIC
C642 4030014420 S.CERAMIC
C643 4030016820 S.CERAMIC
C644 4030016750 S.CERAMIC
C645 4550006320 S.TANTALUM
C646 4030016930 S.CERAMIC
C647 4030014490 S.CERAMIC
C648 4550006690 S.TANTALUM
C651 4030012610 S.CERAMIC
C652 4030013850 S.CERAMIC
C653 4030014490 S.CERAMIC
C654 4030014490 S.CERAMIC
C655 4030013850 S.CERAMIC
C656 4030014490 S.CERAMIC
C657 4030014070 S.CERAMIC
C658 4030014050 S.CERAMIC
C659 4030016930 S.CERAMIC
C662 4030014200 S.CERAMIC
C665 4030016930 S.CERAMIC
C666 4030016930 S.CERAMIC
C667 4030014180 S.CERAMIC
C668 4030014180 S.CERAMIC
J2 6450001680 CONNECTOR
J3 6450001690 CONNECTOR
J4 6450000870 CONNECTOR
J6 6510007080 CONNECTOR
J7 6910010850 CONNECTOR
J8 6510021330 S.CONNECTOR
DS1 5030001640 LCD
DS2 5010000160 S.LED
DS3 5010000160 S.LED
DS4 5040002190 S.LED
MC1 7700002160 MICROPHON
S1 2230000900 S.SWITCH
SP1 2510000960 SPEAKER
W1 7030003860 S.JUMPER
W2 7030003860 S.JUMPER
W6 6910012670 S.JUMPER
W10 7030003860 S.JUMPER
W12 7030003860 S.JUMPER
W13 7030003860 S.JUMPER
W14 7030003860 S.JUMPER
W15 7030003860 S.JUMPER
DESCRIPTION
ECUE1H470JCQ
ECUE1E471KBQ
ECUE1H470JCQ
ECUE1E471KBQ
ECUE1E471KBQ
ECUE1E331KBQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1E331KBQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1E331KBQ
ECUE1E331KBQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1E331KBQ
ECUE1H0R3BCQ
ECUE1H0R5BCQ
ECUE1HR75BCQ
ECUE1H910JCQ
ECST0JY475R
ECJ0EB1A104K
ECUE1E331KBQ
ECST1AC476R
C2012 JB 1C 474K-T-A
ECUE1E102KBQ
ECUE1E331KBQ
ECUE1E331KBQ
ECUE1E102KBQ
ECUE1E331KBQ
ECUE1H040BCQ
ECUE1H030BCQ
ECJ0EB1A104K
ECUE1H101JCQ
ECJ0EB1A104K
ECJ0EB1A104K
ECUE1H470JCQ
ECUE1H470JCQ
HSJ1122-010010
HSJ1456-01-220
HEC2711-01-020
PI28A-02M
IMSA-9230B-1-05Z080-T
AXK530145P
LM-1761B
LNJ310M6URA
LNJ310M6URA
LNJ808R8ERA
KUC3523-040245
JPM1990-2013R
K036NA500-26
ERJ3GE JPW V
ERJ3GE JPW V
MJ-0.4
ERJ3GE JPW V [24 keys] only
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
[MAIN UNIT]
REF ORDER
NO. NO.
W16 7030003860 S.JUMPER
W17 7030003860 S.JUMPER
WS1 8600035811 CABLE
EP1 0910050625 PCB
EP2 8930042590 LCD CONTACT

[VR BOARD]

REF ORDER
NO. NO.
R1 7210002950 VARIABLE
R2 7030004980 S.RESISTOR
R3 7030003480 S.RESISTOR
C1 4030014180 S.CERAMIC
C2 4030014180 S.CERAMIC
C3 4030014180 S.CERAMIC
C4 4030014490 S.CERAMIC
F1 5210000710 S.FUSE
EP1 0910050634 PCB
6 - 6
DESCRIPTION
ERJ3GE JPW V
ERJ3GE JPW V
FX1923 P01MA-1
B 5229E
SRCN-1922-SP-N-W
DESCRIPTION
RV-312
ERJ2GEJ 101 X (100 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1H470JCQ
ECUE1E331KBQ
KAB 2402 322 NA29
B 5230D
S.=Surface mount
