Electrical Installation - RS Flight Systems SCU Front Panel V2 Installation & Operation Manual

4.

Electrical Installation

The Switches of the Front Panel V2 are connected to the Rotax HIC connectors A and B. The detailed
pinout is listed in Table 4-1 and shown in the sketches in Figure 4-1 and Figure 4-2.
Pin Start
Connector Pin
Key Switch
1 -
2 -
3 -
4 -
5 HIC A
6 Lane Switch
7 HIC B
8 Lane Switch
9 -
10 -
11 -
12 -
Installation / Operation Manual
SCU Front Panel V2
Signal Name
- BAT
- BAT
- SCU
- SCU
1 LANE_SEL_SW_A_1
2 LANE_SEL_SW
1 LANE_SEL_SW_B_1
4 LANE_SEL_SW
- BAT_BCKP
- BAT_BCKP
- GND
- GND
Table 4-1: Start Switch Key pinout
Signal Description
BAT Supply
BAT Signal
SCU Supply
SCU Signal
Lane A Supply
Lane A Signal
Lane B Supply
Lane B Signal
BATTERY BACKUP
Supply
BATTERY BACKUP
Signal
EMS GND
Aircraft GND
18.10.2022 | V1.02
Current /
Wire Size
7,5 A
7,5 A
7,5 A
7,5 A
AWG 22
AWG 22
-9-
