Pin Lane
Connector Pin
Switch
1 HIC A
Start Key
2
Switch
3 HIC B
Start Key
4
Switch
5 HIC A
6 HIC A
7 HIC B
8 HIC B
013 HIC B
014 HIC B
18.10.2022 | V1.02
-10-
Signal Name
7 LANE_SEL_SW_A_2
6 LANE_SEL_SW
9 LANE_SEL_SW_B_2
8 LANE_SEL_SW
3 SIG_FUEL_PUMP_1
9 GND_FUEL_PUMP_1
11 GND_FUEL_PUMP_2
3 SIG_FUEL_PUMP_2
4 CONN_STARTER_REL_SW
12 SUPP_START_SWITCH
Table 4-2: Lane Switch Knob pinout
Signal Description
Lane A Supply
Lane A Signal
Lane B Supply
Lane B Signal
Fuel Pump Main Signal
Fuel Pump Main Supply
Fuel Pump AUX Supply
Fuel Pump AUX Signal
Starter Signal
Starter Supply
Installation / Operation Manual
SCU Front Panel V2
Current /
Wire Size
7,5 A
7,5 A
7,5 A
7,5 A
10 A
10 A
10 A
10 A
5 A
5 A
