- Page 1 Refrigerated Showcases Models RS-CN-0120-4D, 0160-4D, 0202-4D, 0252-4D Items 47560, 48887, 47561, 47562 Instruction Manual Revised - 11/10/2022 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model RS-CN-0120-4D / Model RS-CN-0160-4D Model RS-CN-0202-4D / Model RS-CN-0252-4D Section Page Disclaimer -------------------------------------------------------------------------------------------- 3 General Information --------------------------------------------------------------------------- 4 - 5 Safety and Warranty --------------------------------------------------------------------------- 5 - 7 Technical Specifications -------------------------------------------------------------------------- 8 Operation ----------------------------------------------------------------------------------------- 8 - 9... -
Page 3: Disclaimer
Disclaimer OMCAN IS NOT RESPONSIBLE FOR ANY DAMAGES DUE TO WATER LEAKS. WARRANTY FOR WATER LEAKS IS VOID IF THE AMBIENT ROOM TEMPERATURE EXCEEDS 75°F AND 55% RELATIVE HUMIDITY, AND THE APPLIANCE DRAIN IS NOT CONNECTED DIRECTLY TO A FLOOR... -
Page 4: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 5: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 6 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.
- Page 7 Safety and Warranty Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures not improper use. Please see https://omcan.com/disclaimer for complete info. WARNING: The packaging components are classified as normal solid urban waste and can therefore be disposed of without difficulty.
-
Page 8: Technical Specifications
Technical Specifications Model RS-CN-0120-4D RS-CN-0160-4D RS-CN-0202-4D RS-CN-0252-4D Temperature Range 0 - 12°C / 32 - 53.6°F Refrigerant R290 Max Ambient Temp 23.9°C / 75°F Rating Net Volume 88 L / 3.1 cu.ft. 112 L / 3.95 cu.ft. 157 L / 5.54 cu.ft. -
Page 9: Operation
Operation cold. After checking to make sure the refrigerator is working properly, it may be used. FEATURES OF FUNCTION • Small, integrated digital controller, which is applicable to the compressor of 1 Hp. Located behind the front grill. • Main functions are: Temperature Display/Temperature Control/Manual-Automatic /Light Control/Value Storing/Self-Testing/Parameter Locking. -
Page 10: Troubleshooting
Power on. normal operation. Melting process. Stop melting. Refrigerant leaking. Patch the leak and refill refrigerant. Unit failure. Call Omcan. Weak air from air curtain, Evaporator blocked by frost. Increase melting frequency. and higher cabinet Inside fan damaged. Replace the fan. - Page 11 Troubleshooting Normal air curtain, but Condenser contaminated. Clean the condenser. periodical fluctuation of Poor venting of the unit. Improve the venting conditions. cabinet temperature. Heat protection of compressor failure. Replace the heat protection. Capillary is blocked by ice. Replace the drying filter. Temperature controller failure.
-
Page 12: Parts Breakdown
Parts Breakdown Model RS-CN-0120-4D 47560... - Page 13 Parts Breakdown Model RS-CN-0120-4D 47560 Item No. Description Position Item No. Description Position Item No. Description Position AL564 Door Glass for 47560 60119 Switch for 47560 30797 Left Seal for 47560 71639 Door Wheel for 47560 AL575 Left Panel for 47560...
- Page 14 Parts Breakdown Model RS-CN-0160-4D 48887...
- Page 15 Parts Breakdown Model RS-CN-0160-4D 48887 Item No. Description Position Item No. Description Position Item No. Description Position AL596 Door Glass for 48887 AA082 Digital Controller for 48887 22-2 30798 Right Seal for 48887 71639 Door Wheel for 48887 60119 Switch for 48887 30797 Left Seal for 48887 AK105...
- Page 16 Parts Breakdown Model RS-CN-0202-4D 47561...
- Page 17 Parts Breakdown Model RS-CN-0202-4D 47561 Item No. Description Position Item No. Description Position Item No. Description Position AL615 Door Glass for 47561 AA082 Digital Controller for 47561 23-2 30797 Left Seal for 47561 71639 Door Wheel for 47561 60119 Switch for 47561 AA089 Decorative Board for 47561 AK105...
- Page 18 Parts Breakdown Model RS-CN-0252-4D 47562...
- Page 19 Parts Breakdown Model RS-CN-0252-4D 47562 Item No. Description Position Item No. Description Position Item No. Description Position AK104 Door Glass for 47562 AA082 Digital Controller for 47562 23-2 30797 Left Seal for 47562 71639 Door Wheel for 47562 60119 Switch for 47562 AK120 Decorative Board for 47562 AK105...
-
Page 20: Electrical Schematics
Electrical Schematics Model RS-CN-0120-4D 47560 Model RS-CN-0160-4D 48887 Model RS-CN-0202-4D 47561 Model RS-CN-0252-4D 47562... -
Page 21: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... - Page 22 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
-
Page 23: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 24 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
