Summary of Contents for SC&T VE02DALS
- Page 1 VGA Extender User Manual Model : VE02DALS VGA & Stereo Audio/Digital Audio CAT5e Receiver with Skew Corrector and Chainable output Smart Cabling & Transmission Corp. V1.0...
- Page 2 VE02DALS Introduction VE02DALS is a receiver unit for the VGA extender designed for long-distance transmission over a cost-effective CAT5 and an audio cable and has a built-in RGB skew adjustment for the optimum video performance under a long cable run.
- Page 3 User Manual VE02DALS Panel View VE02DALS Adjustment Cable length EQ adjustment for picture sharpness, clockwise turning to enhance signal, counter-clockwise to lower signal. Gain: Video signal gain adjustment for picture brightness, clockwise turning to enhance signal, counter-clockwise to lower signal.
- Page 4 User Manual VE02DALS Caution The cabling must away from any equipment with electromagnetic wave, i.e.: microwave, radio equipment, high voltage lines. Specification ITEM NO. VE02DALS Support Compliance Max. Video Resolution 1920x1200@60Hz Max. Transmission Distance 300M Video Bandwidth 122MHz, -3dB Audio Bandwidth...
