- Page 1 D-series CLASS-D POWER AMPLIFIER Order ref: 172.106UK (D600) 172.110UK (D1000) User Manual Version 2.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 Introduction Thank you for choosing a Citronic D-series power amplifier as part of your sound reinforcement system. Custom class-D circuit design provides an efficient amplifier within a compact and lightweight form factor. Please read this manual fully and follow the instructions to achieve the best results from your amplifier and to avoid damage through misuse.
- Page 3 Operation Connect speaker cabinets to channel outputs (18, 20) using good quality Speakon ® leads and ensure that the combined load on each channel is no lower than 4Ω. For speaker loads connected in parallel… 1/speaker impedance + 1/speaker impedance… = 1/TOTAL impedance.
- Page 4 Specifications Model D600 D1000 AVSL ref. 172.106UK 172.110UK Power supply 200-240Vac, 50/60Hz (IEC) Fuse T8AL 250V T10AL 250V Output: RMS @ 4Ω 2 x 300W 2 x 500W Output: RMS @ 8Ω 2 x 150W 2 x 300W Bridge power: RMS @ 8Ω 600W 1000W Amplifier: construction...
