Shadow-Caster SCM-SLF-WBR Product Instructions

S C M - S L F -W B R S C M - S L F -W B R
WHITE, BLUE AND RED FLUSH MOUNT SPREADER LIGHT WHITE, BLUE AND RED FLUSH MOUNT SPREADER LIGHT
MODEL #: SCM-SLF-WBR-WH
OPERATION
• When power is applied to the light, the brightness slowly ramps up to full
power over approximately 3 seconds
• Toggle power during ramp up to set brightness
• Subsequent power toggles will toggle from blue to red and back to white
• To reset the light, turn off for 10 seconds
INSTALLATION
• Cut hole according to template provided
• Connect power and ground
• Put a 1/8" size ball of silicone sealant in screw holes before mounting
• Screw in light
ON/OFF SWITCH
10-30V
FUSE
Designed & Manufactured Designed & Manufactured
in Clearwater, FL in Clearwater, FL
© 2022 Shadow-Caster © 2022 Shadow-Caster LEDs. All Right Reserved. LEDs. All Right Reserved.
™
P R O D U C T P R O D U C T I N S T R U C T I O N S I N S T R U C T I O N S
GROUND
Shadow-Caster Shadow-Caster LED Lighting | 2060 Calumet Street | Clearwater, FL 33765 LED Lighting | 2060 Calumet Street | Clearwater, FL 33765
™ ™
p: +1 727.474.2877 p: +1 727.474.2877 e: e: info@shadow-caster.com
SPECIFICATIONS
• Power consumption: 2 amps at
12V and 1 amp at 24V
• Mounting depth: 1.5" [37mm]
• IP67 (waterproof)
• Durable glass window
CLEANING INSTRUCTIONS
• Clean with soap and water with a
soft towel or sponge
info@shadow-caster.com w: w: shadow-caster.com shadow-caster.com
2022.11
