Shadow-Caster EAGLE RAY LIGHT BAR Product Instructions

EAGLE RAY LIGHT BAR
HIGH BRIGHTNESS LIGHT BAR
DESCRIPTION
Utilizing automotive lighting technology and novel beam
shaping optics, Shadow-Caster has created the Eagle Ray
- a unique light bar with a combination of focused laser-
driven white light beams and a wide 60° LED flood array
to efficiently light your way.
The focused white lights are ideal for long-distance
viewing and penetrating fog, rain, and mist. The beam
angle and brightness are adjustable with a push button
or the Shadow-Caster NMEA 2000 Light Commander
®
interface.
LASER FEATURES
• Automotive grade laser-driven white lights
• Blue halo illumination around optics indicate power
state
• Adjustable 5-100° beam angle control with a switch or
MFD interface
FLOOD FEATURES
• 24 bright white LEDs
• Blue accent light strips indicate brightness level
• 60° beam angle
• Adjustable brightness control with a switch or MFD
interface
Designed & Manufactured Designed & Manufactured
in Clearwater, FL in Clearwater, FL
© 2024 Shadow-Caster © 2024 Shadow-Caster LEDs. All Right Reserved. LEDs. All Right Reserved.
®
P R O D U C T P R O D U C T I N S T R U C T I O N S I N S T R U C T I O N S
SPECIFICATIONS
• 20,000 lumens
• Billet Aluminum housing in white or black finish
• Remote power trigger to provide simpler installation (main
current supply is not controlled through switch)
• Borosilicate glass window
• 10-30V input
• 200W max power
• 16.5A current draw at 12V DC
• 2.5" H x 20" W x 5.4" D [65.3 x 506.5 x 136.9mm]
DIMENSIONS
3"
[76.5mm]
Shadow-Caster Shadow-Caster LED Lighting | LED Lighting
® ®
p: +1 727.474.2877 p: +1 727.474.2877 e: e: info@shadow-caster.com
20" [506.5mm]
10" [254mm]
5.4"
[136.9mm]
| 2060 Calumet Street 2060 Calumet Street |
info@shadow-caster.com w:
2.5"
[65.3mm]
