- Page 1 LIGHT COMMANDER SCM-LC-N2K NMEA 2000 SCM-LC-N2K-PLUS NMEA 2000 + Ethernet INSTALLATION & OPERATION MANUAL W W W . S H A D O W - C A S T E R . C O M...
-
Page 2: Table Of Contents
BEST PRACTICES FOR MITIGATING NOISE ISSUES ....................BASIC OPERATIONS FOR SHADOW-CASTER MFD USER INTERFACE................. BASIC OPERATIONS FOR SIMRAD NMEA 2000 LIGHTING INTERFACE CONFIGURING ZONES........ TROUBLESHOOTING ..............................DIMENSIONS .................................. Shadow-Caster™ LED Lighting | 2060 Calumet Street. | Clearwater, FL 33765 1+ 727.474.2877 info@shadow-caster.com shadow-caster.com... -
Page 3: Light Commander Box Contents
• SCM-LC-N2K or SCM-LC-N2K-PLUS Light Commander Control up to 6 zones lights (expandable to 12 or 18 • by adding one or two SCM-LC-N2K for 6 additional 4 x SS316 Pan Head #8 x 3⁄4" Mounting Screws channels each). •... -
Page 4: Scm-Lc-N2K Typical Wiring Diagram
Zone 6 rotation’ control. 10-30V Power Source 10-30V Power Source SCM-PD4CH Shadow-NET ™ 4 x channels of RGB(W) lighting (supports up to 15A per channel) Shadow-Caster™ LED Lighting | 2060 Calumet Street. | Clearwater, FL 33765 1+ 727.474.2877 info@shadow-caster.com shadow-caster.com... -
Page 5: Scm-Lc-N2K-Plus Typical Wiring Diagram
Zone 1 Zone 6 rotation’ control. 10-30V Power Source 10-30V Power Source SCM-PD4CH Shadow-NET ™ 4 x channels of RGB(W) lighting (supports up to 15A per channel) Designed & Manufactured in Clearwater, FL © 2021 Shadow-Caster™ LED Lighting, All Rights Reserved... -
Page 6: Connecting Two Light Commanders Typical Wiring Diagram
™ 4 x Channels of RGB(W) lighting (supports up to 15A per channel) 4 x channels of RGB(W) lighting (supports up to 15A per channel) Shadow-Caster™ LED Lighting | 2060 Calumet Street. | Clearwater, FL 33765 1+ 727.474.2877 info@shadow-caster.com shadow-caster.com... -
Page 7: Deutsch Connectors For Lighting And Switch Inputs
PWR + OUT Channel 3 (1 of 2)* PWR + OUT Channel 3 (2 of 2)* * Combine these two outputs together when current exceeds 10A. Designed & Manufactured in Clearwater, FL © 2021 Shadow-Caster™ LED Lighting, All Rights Reserved... -
Page 8: Installation
3, and can be assigned to any zone 1-6. As Shadow-NET™ devices do not draw power through the controller, they do not contribute to the Light Commander's total load calculation. Shadow-Caster™ LED Lighting | 2060 Calumet Street. | Clearwater, FL 33765 1+ 727.474.2877 info@shadow-caster.com shadow-caster.com... -
Page 9: Switch Inputs (Optional)
SCM-SCNET-04 4 meter Cable • SCM-SCNET-Y Y Cable Blue Yellow Green • Press to step to next color • Press and hold to start color rotation Designed & Manufactured in Clearwater, FL © 2021 Shadow-Caster™ LED Lighting, All Rights Reserved... -
Page 10: Connecting Stereo Input For Stereo Music Sync Input
Run RGB power wires as far as possible from the speaker feeds for the stereo. Run separate bundles where possible. Shadow-Caster™ LED Lighting | 2060 Calumet Street. | Clearwater, FL 33765 1+ 727.474.2877 info@shadow-caster.com shadow-caster.com... -
Page 11: Basic Operations For Shadow-Caster Mfd User Interface
Configure Devices Identify all of the lighting devices and then assign them to the desired zone. "Local" refers to built in RGB channels. Designed & Manufactured in Clearwater, FL © 2021 Shadow-Caster™ LED Lighting, All Rights Reserved... - Page 12 Select zones Select lighting mode Select zone color Zone mode indication Zone brightness indication Select RGB mode to use color wheel selector Edit mode parameters Shadow-Caster™ LED Lighting | 2060 Calumet Street. | Clearwater, FL 33765 1+ 727.474.2877 info@shadow-caster.com shadow-caster.com...
- Page 13 To add a single color or custom sequence simply select the color and hit "Add Color". Up to 21 colors can be used in any given sequence. Designed & Manufactured in Clearwater, FL © 2021 Shadow-Caster™ LED Lighting, All Rights Reserved...
- Page 14 Flashes single colors or sequences with changeable rate. RGB COLOR WHEEL Quickly select any color and brightness. FREQUENCY MUSIC SYNC Uses full spectrum digital signal processing to go with the music. Shadow-Caster™ LED Lighting | 2060 Calumet Street. | Clearwater, FL 33765 1+ 727.474.2877 info@shadow-caster.com shadow-caster.com...
-
Page 15: Basic Operations For Simrad Nmea 2000 Lighting Interface Configuring Zones
Zone color indicates current zone color or function Press to slide out lighting interface Select between zones or scene selection SCENE SELECTION Customizable scene menu Designed & Manufactured in Clearwater, FL © 2021 Shadow-Caster™ LED Lighting, All Rights Reserved... - Page 16 BRIGHTNESS ADJUSTMENT SCREEN Adjust brightness Brightness Lighting effects Color selection SINGLE COLOR ADJUSTMENT SCREEN Adjust color and hue DYNAMIC LIGHTING EFFECTS SCREEN Dynamic function selection Shadow-Caster™ LED Lighting | 2060 Calumet Street. | Clearwater, FL 33765 1+ 727.474.2877 info@shadow-caster.com shadow-caster.com...
- Page 17 LIGHT COMMANDER INSTALLATION & OPERATION MANUAL ZONE CONFIGURATION & LIGHT ASSIGNMENT SCREENS Zone configuration and light assignment Zone light assignment Designed & Manufactured in Clearwater, FL © 2021 Shadow-Caster™ LED Lighting, All Rights Reserved...
-
Page 18: Troubleshooting
Shadow-NET™ connected lights. DIMENSIONS 1.79" [45.4mm] 8.9" [226mm] 7.63" [193.7mm] MOUNTING 1.88" [47.6mm] MOUNTING 4.711" [119.7mm] Shadow-Caster™ LED Lighting | 2060 Calumet Street. | Clearwater, FL 33765 1+ 727.474.2877 info@shadow-caster.com shadow-caster.com... - Page 19 JUN23 Shadow-Caster™ LED Lighting 2060 Calumet Street. Clearwater, FL 33765 Designed & Manufactured in Clearwater, FL 1+ 727.474.2877 info@shadow-caster.com shadow-caster.com © 2021 Shadow-Caster™ LED Lighting, All Rights Reserved...
