PRYME PRYMEMAX BTH-600-MAX Quick Start Manual

PRYMEMAX™ BTH-600-MAX
Wireless BT Speaker Microphone
For use with PRYMEBLU Wireless adapters; BK, Icom, and
Kenwood / EF Johnson 2-way radios with built-in BT connectivity;
and for PTT Over-Cellular apps such as ES Chat, Team on the
Run/Team on Mission, Unity Intercom, and Zello on IOS
and Android smart phones.
Model No.: BTH-600-MAX
FCC ID XTS-BTH-600
PRYME® and PRYMEBLU® are trademarks owned by PRYME Radio Products,
Brea CA. All other product or service names are the property of their respective owners.
© 2022 PRYME Radio Products, Brea CA. All Rights Reserved

Charging the Speaker Microphone

The BTH-600-MAX Speaker Microphone has a
Lithium Ion rechargeable battery pack which
must be charged prior to operation, and must be
recharged regularly. A fully charged battery will
provide up to 40 hours of continuous operation
before needing to be recharged. However,
operating time can vary depending on usage and
the condition of the battery pack. Recharge the
battery regularly.
To charge the Speaker Microphone
1. Ensure the device is turned off using the multifunction button.
2. Plug the charge cable into any powered USB outlet, such as
an AC wall charger, and then into the charge jack
on the Speaker Microphone.
3. Once the charging process has begun, the LED indicator
on the Speaker Microphone will show a constant red light.
4. Typical charge time is approximately five hours. Actual charge time
will vary depending on several factors including the battery's charge state, condition, and age.
5. When the battery is fully charged the LED indicator on the side of the Speaker Microphone
will turn off.
6. Disconnect the charger from the microphone when charging is completed.
Charging Cautions:
- Do not use a wall charger or charge cable that appears to be damaged. (Example: frayed wires,
melted plastic, etc.) Contact PRYME to get a new manufacturer-approved replacement charger.
- Do not tamper with or modify the Speaker Microphone or charger.
- Always turn the Speaker Microphone off when charging.
Made in Taiwan
3

Controls and Connection

Front Firing Speaker
Received calls are heard over this speaker.
The volume level can be controlled using
either the Volume Up / Down buttons on
the Speaker Microphone, or by using the
volume controls on the
two-way radio or phone.
PTT Button
This button is used to
activate the push-to-talk
feature of the 2-way radio
or phone.
Clothing Clip
The alligator-type clip secures the
Speaker Microphone to the user's
clothing during use. The clip can be
rotated to allow the Microphone to
be better positioned.
Phone Button
This button is used to
answer or hang up phone
calls when the BTH-600-MAX
is connected to a cellphone.
Earphone Jack
This jack is used to connect an (optional)
wired listen-only earphone to the Speaker
Microphone for enhanced privacy.
Charge Jack
This USB-C jack is used only to recharge the
removable battery of the Speaker Microphone
by connecting the BTH-600-MAX to a USB charger
or any powered USB source

Pairing with a PRYMEBLU Radio Adapter, 2-Way Radio, or Phone

The BTH-600-MAX speaker microphone is designed to work
with PRYMEBLU wireless adapters, and two-way radios with
internal BT made by BK, Icom, and Kenwood/EF Johnson,
as well as smartphone and tablets running either the
Android orApple iOS operating systems. Prior to normal
operation, the handset and speaker microphone must
be paired together using the following process:
• Hold down the Multifunction Button on the PRYMEBLU Speaker Microphone. Continue to hold the
button down for approximately 3 seconds, until you see the LED on the Speaker Microphone begin to
quickly flash RED-BLUE-RED-BLUE in sequence. The PRYMEBLU Speaker Microphone is now in pairing
mode.
• If you are pairing the microphone to a PRYMEBLU adapter, place the adapter into pairing mode
following the instructions in the user's manual for that device. Typically, this is done by holding down
the PTT button on the adapter while powering the adapter or attached two-way radio on and then
continuing to hold the PTT button down until the LED on the adapter flashes two times per second.
• If you are pairing the microphone with an Icom or Kenwood/EF Johnson two-way radio, follow the
manufacturer's instructions to have the radio scan for nearby headset devices. Once it finishes scanning,
select the PRYMEBLU microphone from the list of nearby devices.
* If you are pairing the microphone with a smartphone, make sure that the smartphone's BT slider is
turned on and then use the phone's BT menu to scan for nearby devices. Select the device named
"BTH-PTT" to pair with the phone.
• After a few seconds, the two devices should sync to one another. Once the PRYMEBLU Speaker
Microphone and Adapter, Radio, or Phone are paired with each other the status LED on the Speaker
Microphone will then show one FLASH every few seconds.
• Once successfully paired, you will be able to operate your 2-way radio using the PRYMEBLU Speaker Mic.

Reconnecting a Previously Paired Speaker Microphone and Two-Way Radio or Phone

Once the PRYMEBLU Speaker Microphone and adapter, radio or phone have been successfully paired
together, both devices will remember that connection. The adapter/radio and Speaker Mic will attempt
to re-establish their link whenever the adapter, radio or phone and Microphone handset are both
powered on and in within range of each other. Re-establishing this connection can take 10-60 seconds.
Microphone:
This Microphone picks up the user's
voice audio when sending a call.
Volume Up and Down Buttons
These buttons can be used to turn
the receive audio volume of the
Speaker Microphone up or down
in five preset steps.
Status LEDs
The red and blue LEDs flash
messages that let the user
know the current status of
the Speaker Microphone.
Multifunction Button
Holding down this button for one second
will turn the Speaker Microphone on and off.
This button can also be used to place the Speaker
Microphone into pairing mode so that it can be
connected wirelessly to a phone or radio.
