PRYME PRYMEBLU WTX-PTT1500D User Manual

Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
To maintain compliance with FCC RF exposure compliance requirements, please avoid direct contact to
the transmitting antenna during transmitting.
RF Exposure Warning!
This device contains transmitters and receivers which emit Radio Frequency (RF) energy. The device
is designed to comply with the limits for exposure to RF energy set by the Federal Communications
Commission (FCC) of the United States, Industry Canada (IC) of Canada, and the regulating entities
of other countries.
If you are still concerned about exposure to RF energy,
you can further limit your exposure by limiting the
amount of time you use the equipment or by placing
more distance between your body and the device,
since exposure level drops off dramatically
with distance.
Version 1.00 August 2017
Controls and Connections
ACCESSORY JACK
This jack accepts a 5-pin threaded DIN connector and is
used to connect the WTX-1500D to a PRYME headset,
throat mic, or other audio accessory (sold separately).
AUX PTT / STATUS LED
The LED shows the status of the
WTX-1500D's Bluetooth link and
the auxiliary button can be used to
activate the Push-to-Talk feature of
your two-way radio.
MAIN (FRONT-FACING) PTT
This button is used to activate
the Push-to-Talk feature of
your two-way radio.
CLOTHING CLIP
This rotating alligator style clip is used
to secure the PTT to the user's clothing
or to other safety equipment such as a
tactical vest.
911 Mariner St., Brea, CA 92821
PH: 714.257.0300 FAX: 714.257.0600
TOLL FREE: 800.666.2654
2
WWW.PRYME.COM
RADIO CONNECTOR
This connector is used to
attach the WTX-PTT1500D to
the accessory connector of a
compatible 2-way radio.
3
PRYMEBLU WTX-PTT1500D
®
Waterproof Tactical Push-to-Talk Button With Wireless Bluetooth
User's Guide
For use with PRYME's Throat
Mics, Headsets, and other
Tactical Audio Accessories
Note: BT-PTT-Z wireless PTT shown.
Applies to Model Nos.: WTX-PTT-1511D, WTX-PTT-1523D, WTX-PTT-1537D,
WTX-PTT-1555D, WTX-PTT-1583D, WTX-PTT-1500-M11D and others
Made in Taiwan
PRYME® and PRYMEBLU® are trademarks owned by PRYME Radio Products,
Brea CA. All other product or service names are the property of their respective owners.
© 2017 PRYME Radio Products, Brea CA. All Rights Reserved
Setting up the WTX-PTT1500D for Operation
CONNECTING A WIRED HEADSET
The WTX-PTT1500D requires a compatible wired headset or other audio accessory (sold separately).
To attach the headset, insert the 5-pin DIN connector of the headset or other audio accessory into
the jack on the WTX-1500D. Then tighten the threaded ring to secure the connector into place.
PRYME makes a wide variety of compatible audio accessories for different environments and
applications. For a list of compatible accessories see PAGE 7.
CONNECTING TO A TWO-WAY RADIO
Always make sure that the radio is turned off before connecting or disconnecting the
WTX-PTT1500.
Connect the WTX-PTT1500D to the radio by attaching the radio connector to the accessory jack on
the radio. On some two-way radios, there may be a latch or one or more screws that need to be
tightened to secure the connector in place.
4
