H.d. lawn roller (24" dia. x 48" wide)

Advertisement

Quick Links

OWNERS
MANUAL
MODEL NO.
45-02164
45-02163
SAFETY PRECAUTIONS
1. Never attach a garden hose to the fi ll/drain hole when
fi lling. Dangerous pressure build up could occur inside
roller.
2. Do not fi ll roller to maximum weight without checking
capability of vehicle to safely pull and stop.
3. Never use roller up and down hills; always work across
hills and slopes.
4. Use caution when turning, slowing or stopping.
5. Always drain roller to keep from freezing.
Printed in USA
© 2004 Agri-Fab, Inc.
H.D. LAWN ROLLER
(24" Dia. x 48" Wide)

SPECIFICATIONS:

Roller Drum:
O.A. Width:
Bearings:
Tow Hitch:
Weight w/ Water: Up to 910 Lbs. Filled with Water
Approx. Sh. Wt.: Approximately 165 Lbs.
24" Dia. x 48" Wide Welded Steel
Approximately 52"
1" I.D., Replaceable
Std. Pin Type - 1/2" Hole
(Note: May be fi lled with sand)
Form No. 40255 (9/06)
