Agri-Fab 45-0260 Owner's Manual

Agri-Fab 45-0260 Owner's Manual

42 heavy duty lawnsweeper
Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNERS
MANUAL
Model No.
45-0260
190-163-100
190-163-190
CAUTION:
Read Rules for
Safe Operation
and Instructions
Carefully
PRINTED IN U.S.A.
42" Heavy Duty
LAWNSWEEPER
• Safety
• Assembly
• Operation
• Maintenance
• Parts
FORM NO. 46814 (REV. 7/98)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 45-0260 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Agri-Fab 45-0260

Summary of Contents for Agri-Fab 45-0260

  • Page 1 OWNERS MANUAL Model No. 45-0260 190-163-100 190-163-190 42" Heavy Duty LAWNSWEEPER CAUTION: • Safety Read Rules for Safe Operation • Assembly and Instructions • Operation Carefully • Maintenance • Parts PRINTED IN U.S.A. FORM NO. 46814 (REV. 7/98)

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY RULES...............2 MAINTENANCE..............12 FULL SIZE HARDWARE CHART........3 STORAGE...............12 CARTON CONTENTS............4 SERVICE AND ADJUSTMENTS........13 SWEEPER ASSEMBLY INSTRUCTIONS......5 TROUBLESHOOTING............13 HOPPER ASSEMBLY INSTRUCTIONS......7 REPAIR PARTS EXPLOSION........14 KNOW YOUR SWEEPER..........11 REPAIR PARTS LIST.............15 HOW TO USE YOUR SWEEPER........11 SAFETY Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times, when using power equipment.

  • Page 3: Full Size Hardware Chart

    HARDWARE PACKAGE CONTENTS SHOWN FULL SIZE NOT SHOWN FULL SIZE REF. QTY. DESCRIPTION REF. QTY. DESCRIPTION Hex Bolt, 5/16-18 x 3" Lg. Flat Washer, 5/16" Std. Wrt. Hex Bolt, 5/16-18 x 2-1/4" Lg. Flat Washer, 5/16" (Small) Hex Bolt, 5/16-18 x 1-3/4" Lg. Lock Washer, 5/16"...

  • Page 4: Carton Contents

    ASSEMBLY CARTON CONTENTS (Loose Parts in Carton) 1. Sweeper Housing Assembly 10. Hopper Bag 2. Bag Arm Tube (2) 11. Windscreen 3. Hitch Tube, L.H. 12. Upper Hopper Tube, R.H. 13. Upper Hopper Tube, L.H. 4. Hitch Bracket 5. Hitch Bracket (Straight) 14.

  • Page 5: Sweeper Assembly Instructions

    ASSEMBLY OF SWEEPER 5/16" x 3" HEX BOLT TOOLS REQUIRED FOR ASSEMBLY 5/16" FLAT HEIGHT Pliers WASHER ADJUSTMENT (SMALL) Screwdriver STRAP Hammer Adjustable Wrench SPACER 9/16" Open End or Box End Wrench BUSHING 7/16" Open End or Box End Wrench 1/2"...
  • Page 6 If your tractor hitch has 8" to 10" ground clearance, 10. Assemble the height adjustment handle to the height use the instructions below to assemble the sweeper adjustment tube using the curved bolts, washers and hitch brackets. If your tractor hitch has more than 10" nuts which come pre-assembled to the tube.

  • Page 7: Hopper Assembly Instructions

    ASSEMBLY OF HOPPER BAG 4. Assemble the two lower hopper tubes together using a 1/4" x 1" curved head bolt and a 1/4" hex lock nut. See fi gure 10. 1. Insert the left hand upper hopper tube through the stitched fl...
  • Page 8 7. Assemble the bag retainer and the bag frame strap to IMPORTANT: Do not over bend the support rods during the front edge of the bag bottom. Place the bag retainer the following step. Over bending will cause the spring steel on top and the bag frame strap underneath the bag bot- rods to loose supporting tension.
  • Page 9 16. Secure the rope to the top center of the hopper bag 13. Slide the hopper bag pivot rod through the side of an frame as shown in fi gure 20. upper hopper tube where the hole was pierced. Assemble onto the rod a mounting clamp, two bag arm tubes and another mounting clamp as shown in fi...
  • Page 10 ATTACHING SWEEPER HITCH TO TRACTOR BRUSH HEIGHT ADJUSTED 1. Place the tractor and sweeper on a fl at level surface. APPROXIMATELY MID-WAY 2. Set the sweeper height adjustment handle to about the middle of its adjustment range. 3. Attach the sweeper hitch to the tractor hitch, arranging the 3/4"...

  • Page 11: Know Your Sweeper

    OPERATION KNOW YOUR SWEEPER HEIGHT PIVOT ROD BAG ARM TUBE ADJUSTMENT HANDLE WINDSCREEN HOPPER ROPE KNOB HEIGHT HEIGHT ADJUSTMENT ADJUSTMENT STRAP STRAP HITCH BRACKETS HOPPER BAG Hopper Bag Collects grass clippings, leaves and debris. Hopper Rope Permits dumping of hopper bag from the drivers seat. Windscreen Helps prevent collected material from being blown out of hopper bag.

  • Page 12: Maintenance

    MAINTENANCE CUSTOMER RESPONSIBILITIES Read and follow the maintenance schedule and the procedures listed in the maintenance section. MAINTENANCE SCHEDULE Fill in dates as you Service Dates complete regular service. Check for loose fasteners Check for worn or damaged parts Lubricate brush shaft bearings Lubricate wheel bearings Clean Sweeper Clean/Lubricate gears...

  • Page 13: Service And Adjustments

    SERVICE AND ADJUSTMENTS WHEEL GEAR AND PAWL SERVICE BRUSH REPLACEMENT IMPORTANT: Do not remove both wheels at the same NOTE: Brush replacement should be done one brush at time to avoid mixing of parts. (The R.H. and L.H. ratchet a time. gears are not interchangeable.) Make notes on the position of washers and snap rings during disassembly.

  • Page 14: Repair Parts Explosion

    REPAIR PARTS FOR MODEL 45-0260 - 42" LAWNSWEEPER...

  • Page 15: Repair Parts List

    PARTS REPAIR PARTS LIST FOR MODEL 45-0260 - 42" LAWNSWEEPER REF. PART QTY. DESCRIPTION REF. PART QTY. DESCRIPTION 46776 Hitch Tube, R.H. 46731 Tube, Upper Hopper Frame L.H. 46777 Hitch Tube, L.H. 46732 Tube, Lower Hopper Frame R.H. 24182 End Plate, R.H.
  • Page 16 REPAIR PARTS 303 West Raymond Sullivan, IL. 61951 217-728-8388...

This manual is also suitable for:

190-163-100190-163-190
