OWNERS
MANUAL
MODEL NO.
45-02162
SAFETY PRECAUTIONS
1. Never attach a garden hose to the fill/drain hole when
filling. Dangerous pressure build up could occur inside
roller.
2. Do not fill roller to maximum weight without checking
capability of vehicle to safely pull and stop.
3. Never use roller up and down hills; always work across
hills and slopes.
4. Use caution when turning, slowing or stopping.
5. Always drain roller to keep from freezing.
Printed in USA
™
© 2004 Agri-Fab, Inc.
H.D. LAWN ROLLER
(24" Dia. x 48" Wide)
SPECIFICATIONS:
Roller Drum:
O.A. Width:
Bearings:
Tow Hitch:
Weight w/ Water: Up to 910 Lbs. Filled with Water
Approx. Sh. Wt.: Approximately 165 Lbs.
24" Dia. x 48" Wide Welded Steel
Approximately 52"
1" I.D., Replaceable
Std. Pin Type - 1/2" Hole
(Note: May be filled with sand)
Form No. 49537 (10/04)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Agri-Fab 45-02162
Summary of Contents for Agri-Fab 45-02162
-
Page 1: Safety Precautions
3. Never use roller up and down hills; always work across Approx. Sh. Wt.: Approximately 165 Lbs. hills and slopes. 4. Use caution when turning, slowing or stopping. 5. Always drain roller to keep from freezing. Printed in USA © 2004 Agri-Fab, Inc. Form No. 49537 (10/04) -
Page 2: Assembly Instructions
Cotter Pin, 5/32" x 1-1/2" 43528 Flat Washer, 1" 47623 Hitch Pin 46782 Hex Bolt, 5/16-18 x 3" 43343 Hair Cotter Pin 1/8" REPAIR PARTS Agri-Fab, Inc. 303 West Raymond Sullivan, IL. 61951 217-728-8388 www.agri-fab.com the fastest way to purchase parts www.speedepart.com...
