Val-C12-720G Chassis
Installation Guide
HOW TO INSTALL VALKYRIE TEST MODULES
Version 5.1
Xena Networks ApS
Gammel Lundtoftevej 1B, 2
nd
floor
2800 KGS Lyngby
Denmark
www.xenanetworks.com
© Xena Networks – May 2022
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ValkyrieBay Val-C12-720G and is the answer not in the manual?

Questions and answers

Summary of Contents for Xena Networks ValkyrieBay Val-C12-720G

  • Page 1 Val-C12-720G Chassis Installation Guide HOW TO INSTALL VALKYRIE TEST MODULES Version 5.1 Xena Networks ApS Gammel Lundtoftevej 1B, 2 floor 2800 KGS Lyngby Denmark www.xenanetworks.com © Xena Networks – May 2022...
  • Page 2: Specifications

    When you unpack the chassis, make sure the following items is included in the box: • 1 x ValkyrieBay Chassis (Val-C12-720G) • 1 x Power cord • 1 x Xena "Quick Start Guide" • 1 x ValkyrieBay (Val-C12-720G) Chassis Installation Guide • 6 x 12V power splitter cables © Xena Networks – May 2022...
  • Page 3: Quick Overview

    For ports that are not in use, keep dust caps mounted  Do not cover the front or rear ventilation openings in the chassis  Clean the chassis min. every 12 months to remove dust, using compressed air to ensure optimal ventilation © Xena Networks – May 2022...
  • Page 4 It is very important that the retraining bar is installed during transport. On the restraining bar the alignment bar and the top fan bar are attached. © Xena Networks – May 2022...
  • Page 5 STEP 2 (cont.): Place the retaining bar and the attached alignment bar and top fan as shown below © Xena Networks – May 2022...
  • Page 6 STEP 2 (cont.): If necessary, unplug the fan power supply © Xena Networks – May 2022...
  • Page 7 STEP 3: Remove front bracket and install modules in the chosen slots. © Xena Networks – May 2022...
  • Page 8 STEP 4: Slide the test module so it’s aligned with the chassis front, and press it firmly into the slot. STEP 4 (cont.): b Fasten the test module with the screws removed in Step 3 © Xena Networks – May 2022...
  • Page 9 If needed (see list on page 3), connect 12 V power cable (Use delivered 12V splitter cable) STEP 6: If fan bar power cable was detached in step 2 remount this power cable Position the restraining bar in place and fasten the two screws. © Xena Networks – May 2022...
  • Page 10 STEP 7: Remount top lid and fasten it with the two finger screws (Do not operate the chassis without top lid) © Xena Networks – May 2022...
  • Page 11 © Xena Networks – May 2022...
  • Page 12 To minimize the risk of damage, please remove “long” test modules before transportation. This includes any test module(s) that extend past the metal restraining bar under the chassis lid. Always use the original Xena boxes for shipping (including the polystyrene foam and anti-static bags). © Xena Networks – May 2022...
