- Page 1 ValkyrieBay Chassis Installation Guide HOW TO INSTALL VALKYRIE AND CHIMERA TEST MODULES Version 4.0 Xena Networks ApS Lottenborgvej 26, 2nd floor 2800 KGS Lyngby Denmark www.xenanetworks.com © Xena Networks – October 2019...
-
Page 2: Specifications
• 1 x ValkyrieBay Chassis (Val-C12-720G or Val-C12-2400G) • 1 x Power cord • 1 x Xena "Quick Start Guide" • 1 x ValkyrieBay Chassis Installation Guide • 6 x 12v Power splitter cables © Xena Networks – October 2019... -
Page 3: Quick Overview
To minimize the risk of damage, please remove “long” test modules before transportation. This includes any test module(s) that extend past the metal restraining bar under the chassis lid. Always use the original Xena boxes for shipping (including the polystyrene foam and anti-static bags). © Xena Networks – October 2019... - Page 4 The metal support bar holds test modules securely in place. This is very important during transport. It is also used to mount the fans that cool the chassis. These are attached to the chassis by four screws © Xena Networks – October 2019...
- Page 5 © Xena Networks – October 2019...
- Page 6 If necessary, disconnect the plug that powers the fans. © Xena Networks – October 2019...
- Page 7 The cover at the front of the slot needs to be removed before you can slide the new test module into place. You only need to remove one screw which you then (re)use in the next step. © Xena Networks – October 2019...
- Page 8 (those shipped before mid- 2017), the plastic rail needs to be unscrewed and removed. There are 3 versions of the rails but all are mounted on the “top” of the test modules (as shown below). © Xena Networks – October 2019...
- Page 9 This photo shows the screw that needs to be removed. © Xena Networks – October 2019...
- Page 10 Once you are satisfied with the positioning of both support bars, screw the Four lock screws firmly in place. (It can require a little juggling to ensure a proper fit.) STEP 7: Replace the top cover, by sliding it back into place and tightening the 2 screws at the back. © Xena Networks – October 2019...
- Page 11 Simply detach it from the motherboard and you can easily replace the watch or button cell battery. © Xena Networks – October 2019...
- Page 12 There are small differences depending on which test modules you are installing in the ValkyrieBay. The 6-port 10G test module (Odin-10G-1S-6P) has a power socket that attaches to the test module, using a ‘2-to-1’ adapter as shown below. © Xena Networks – October 2019...
- Page 13 © Xena Networks – October 2019...
- Page 14 40GE/100GE Test Module Power Cable In the photo below, you can see these four different test modules: 1. the short six-port Odin-1G-3S-6P (B) 2. the mid-size Odin-10G-1S-2P 3. the large Odin-40G-2S-2P 4. the 2-slot tri-speed Loki-100G-3S-1P © Xena Networks – October 2019...
- Page 15 To minimize the risk of damage, please remove “long” test modules before transportation. This includes any test module(s) that extend past the metal restraining bar under the chassis lid. Always use the original Xena boxes for shipping (including the polystyrene foam and anti-static bags). © Xena Networks – October 2019...
