V 2.8
2-1/2 in.
Tachometer
SPECIFICATIONS
Indicator Range
Display Diameter
Voltage Rating
SAFETY
IMPORTANT SAFETY PRECAUTIONS
WARNING! The operator must follow basic precautions to reduce the risk of personal injury and/or
damage to the equipment.
NOTE: Keep this manual for safety warnings, precautions, installation and maintenance instructions.
PERSONAL SAFETY
1.
Head Protection
a.
Always wear impact safety goggles that provide front and side protection for the eyes.
2.
Foot Protection
b.
Non-skid footwear is recommended to maintain footing and balance.
3.
Control the tool, personal movement and the work environment to avoid personal injury or
damage to tool.
a.
Do not operate any tool when tired or under the influence of drugs, alcohol or medications.
b.
Do not overreach when operating a tool. Proper footing and balance enables better control
of a tool in unexpected situations.
Please read and understand all instructions before use.
Retain this manual for future reference.
User Manual
0 to 7,000 RPM
2-1/2 in.
12V
4230082
