- Page 1 User Manual Version 1.0.1 2021/03/04 www.sysbas.com...
- Page 2 User Manual Revision History Document Pages Revision Date Revised/Added/Removed Details of Revision Ver. Revised 2021.03.04 1.0.1...
-
Page 3: Table Of Contents
User Manual Contents 1. BEFORE USING------------------------------------------------------------------------------------------------------------- 5 2. COMPONENTS -------------------------------------------------------------------------------------------------------------- 6 3. PRODUCT -------------------------------------------------------------------------------------------------------------------- 7 4. HOW TO USE ---------------------------------------------------------------------------------------------------------------- 9 5. GET STARTED -------------------------------------------------------------------------------------------------------------11 6. HOW TO CONNECT ------------------------------------------------------------------------------------------------------11 7. SETTINGS ------------------------------------------------------------------------------------------------------------------ 13 8. SETTINGS USING UTILITY -------------------------------------------------------------------------------------------- 19 ----------------------------------------------------------------Appendix-------------------------------------------------------------- 1. - Page 4 User Manual Please be sure to read this manual before using and use the product safely and accurately. • Pictures and photos in the manual may be different from the physical, and the document is subject to change without notice to improve performance. For the last information, please visit our website (www.sysbas.com).
-
Page 5: Before Using
RS232/422/485 compliant equipment. Maximum communication speed is 921.6Kbps for serial and 100Mbps for Ethernet. sLAN/all-PoE is a device that connects various serial equipment to the network and remote controls, monitors over the network. ● Communication Speed up to 921.6Kbps ●... -
Page 6: Components
User Manual 2. Components Components Ordering Information sLAN/all-PoE, LAN Cable, Ejector Pin, sLAN/all-PoE (Micro-USB B type) Product Warranty & Download Guide... -
Page 7: Product
User Manual 3. Product State Operation Turns ON briefly and then OFF when Power ON. RDY(Yellow) Blink Flashes when Booting is complete. TXD (Green) Blink Flashes when serial data is transmitted. RXD (Red) Blink Flashes when serial data is received. - Page 8 User Manual Connector Front Back (Micro USB Type ) Front: • Serial Port(DB9 Male): RS232/RS422/RS485 (Please refer to the APPENDIX for pin specifications) Back: • PWR: Micro USB Type B • LAN Port: This port(RJ45) is used to connect sLAN/all PoE to Ethernet card, hub, router and other wired network- connected equipment.
-
Page 9: How To Use
① PC – Serial Equipment Connection For the most common example, the PC and sLAN/all PoE are connected to the network, allowing the PC to use serial devices connected to the sLAN/all-PoE. ② Serial Communication Tunneling By extending the serial cable between the PC and the serial equipment via the network, it can be used like a serial cable with no distance limit. - Page 10 User Manual ③ COM Port Redirection By using Redirection, users can use the serial port of sLAN/all PoE connected to the network as if it were a PC- mounted serial port. Factory / Industrial Automation PLC, Robot Arm, Human-Machine Interface, Logistics Warehouse Rail...
-
Page 11: Get Started
PoE and the other to the network equipment. 6. How to Connect The following methods are used to connect sLAN/all-PoE to devices and networks: Power On for the First Time First, check if the input voltage supplied to sLAN/all PoE matches the specification of the model and supply the correct voltage. - Page 12 User Manual...
-
Page 13: Settings
User Manual 7. Settings Precaution for Web Access Web setting is not supported in the network environment below 10Mbps as shown below: Therefore, if you use the Web to change the settings, you must be in 100Mbps network environment or connect the integrated device to a PC as shown below. - Page 14 User Manual Network Setting Network Setting page will be displayed in the initial screen of the Web setting, which shows the Network information of the equipment as below: You can set network environments and network management in the Networking Setting page. Once you have changed the settings, you must press the [Submit] button to save the changed value and restart it through the [Reboot] menu to apply them to actual equipment operation.
- Page 15 User Manual Operation Setting You can set the operating mode and network socket options in the Operation Settings page. Once you have changed the settings, you must press the [Submit] button to save the changed value and restart it through the [Reboot] menu to apply them to actual equipment operation.
- Page 16 User Manual Menu Default Description When UDP packets are received to the socket number waiting for a connection, data is sent to the serial port, and data entered into the serial port is made into UDP packets and sent to the Client.
- Page 17 User Manual Serial Setting You can set the operating environment for serial ports in the Serial Settings page. Once you have changed the settings, you must press the [Submit] button to save the changed value and restart it through the [Reboot] menu to apply them to actual equipment operation.
- Page 18 User Manual Menu Default Description Set the number of stop bit Stop Bits (Option: 1, 2) Set the parity check method Parity (Option: No, Odd, Even) Set the flow control method When the RTS/CTS option is selected, the RTS signal line is automatically...
-
Page 19: Settings Using Utility
When you run SGConfig and click Search, it will discover the sLAN/all PoE connected to the network. When you select the list of devices discovered in the list that you want to set up and click Configure, a window appears to set up sLAN/all-PoE as shown below. Setting Select the device you want to set up among the discovered devices and click [Configure]. -
Page 20: Appendix
User Manual ------------------------------- APPENDIX ---------------------------- 1. Dimension... -
Page 21: Serial Port Pin
User Manual 2. Serial Port Pin Assignment Pin No. RS-232 RS-422 RS-485 TXD- TRXD- TXD+ TRXD+ RXD+ RXD-... -
Page 22: Port(W/Poe Pd Function)
User Manual 3. RJ-45 Port (w/PoE PD function) Signal Description TXD+ Transmit Data + TXD- Transmit Data - RXD+ Receive Data + Vin+ Connect PSE + Vin+ Connect PSE + RXD- Receive Data - Vin- Connect PSE - Vin-... -
Page 23: Reset Switch (Tact)
User Manual 5. Reset Switch (Tact) Function Operation Result Warm Booting Press button less than 3 seconds Restart sLAN/all PoE Factory Default Press button more than 3 seconds Reset sLAN/all PoE settings... -
Page 24: Specification
User Manual 6. Specification Ethernet 10/100Mbps RJ45 Port x 1 LAN Port Static IP, Dynamic IP Ethernet Protocol TCP, UDP, ICMP, DHCP, HTTP, IPv4 Power over Ethernet(PD) IEEE 802.3 10/100 Base-TX , IEEE 802.3af Serial Port 1port DE-9 Male... - Page 25 User Manual Ordering Information sLAN/all PoE Package sLAN/all PoE, LAN cable, Ejector pin sLAN/all(Micro-USB)
-
Page 26: Trouble Shooting
User Manual 7. Trouble Shooting This part suggests solutions to various problems that may arise when using the equipment. Installation If you cannot access the equipment connected via sLAN/all PoE, it is recommended to check the network connection and cables first. -
Page 27: Certification
Test Item: KN 61000-4-2, KN 61000-4-3, KN 61000-4-4, KN 61000-4-5, KN 61000-4-6, KN 61000-4-11 Copyright Copyright ⓒ 2021 SystemBase CO., Ltd. All rights reserved. This manual is a document protected by Copyright law. Unauthorized copying, duplicating, publishing of some or all of contents without prior consent from SystemBase is against Copyright Law. - Page 28 If you have any inconvenience while using the product, please contact us. Email: Working Hour • Purchase/Quotation: overseas@sysbas.com MON ~ FRI 9:00 ~ 18:00 • Technical Support/RMA: tech@sysbas.com www.sysbas.com Tel: +82-2-855-0501 Copyright ⓒ 2021 SystemBase Co., Ltd. All Right Reserved. Fax: +82-2-855-0580...
